HIMA X-DI 32 04 (XDI3204) HIMax 32-Channel Digital Input Module with SOE

Product Description
X-DI 32 04 is a 32-channel safety digital input module developed by HIMA Germany for the HIMax safety instrument system (SIS). It adopts 24VDC input and integrates SOE Sequence of Events event sequence recording function. The module collects field discrete signals such as limit switches, relay contacts and emergency stop signals, performs signal filtering and line fault diagnosis, and uploads data to HIMax safety CPU. It complies with IEC61508 SIL3 and PL e safety standards, supports hot-swap replacement without system shutdown. Installed on HIMax baseplate, widely used as original spare I/O card for petrochemical, power plant ESD and burner safety control cabinets.

Key Functions

• 32-channel 24VDC safety digital input acquisition for field contact and switch signals
• Built-in SOE sequence of events recording, high-precision time stamp for fault event tracing
• Per-channel line monitoring to detect open circuit, short circuit and ground fault
• Programmable input signal filtering range: 2ms ~ 500ms to suppress field noise
• Hot swap support, online module replacement without stopping the SIS safety system
• Continuous hardware self-diagnosis for module circuit and channel health monitoring
• High density slim structure, saving cabinet installation space
• Communicate with HIMax safety controller via internal backplane safety bus

Application Scenarios

• HIMA HIMax safety instrumented system (SIS) ESD emergency shutdown system
• Oil & gas, petrochemical, LNG plant safety interlock control cabinet
• Power station boiler, turbine, burner management safety control system
• Chemical process safety protection system, safety interlock status signal collection
• SIS system renovation, spare I/O module replacement and spare inventory backup

FAQ

Q: Who manufactures X-DI 32 04?
A: HIMA Paul Hildebrandt, Germany, belongs to HIMax X-series safety I/O module family.

Q: What is the special feature of X-DI 32 04?
A: It has built-in SOE event sequence recording function for accurate time marking of safety events.

Q: What safety level can this module reach?
A: SIL3 (IEC61508), PL e.
