Brief Product Description

Honeywell CC-TDIL01, part number 51308386-175, is simplex digital input IOTA terminal assembly for Honeywell Experion PKS Series C rack. It is the field marshalling baseplate matched with CC-PDIL01 32-channel 24VDC digital input IOM module. It provides terminal blocks for discrete field wiring, supports dry contact and 24VDC wet contact input. It supplies non-incendive field excitation power for field contact signals, with open wire detection function. Transmit field on/off signals to IOM via ribbon cable, built-in surge suppression and shield grounding terminals for anti-interference. Fully tested surplus and refurbished Honeywell CC-TDIL01 (51308386-175) modules are available for legacy Experion PKS system maintenance, spare replacement and plant retrofit projects.

Core Product Functions

• Simplex 32-channel 24VDC digital input IOTA for Experion PKS Series C rack
• Field wiring terminal block for valve feedback, limit switch, motor status and interlock contact signals
• Matched with CC-PDIL01 32-channel 24VDC digital input IOM module
• Supports dry contact / wet 24VDC input, onboard non-incendive field excitation power
• Built-in surge protection and shield grounding terminals to suppress field surge interference
• Open wire detection for field cable break diagnosis, onboard LED status indicators
• Transmit discrete field signals to IOM card through dedicated ribbon cable
• Support signal debounce function configured from IOM side to prevent false triggering
• Supports hot-swap replacement following LOTO safety procedures

Application Scenarios

• Legacy Honeywell Experion PKS C300 DCS discrete signal wiring termination cabinet
• Thermal power plant boiler and turbine valve feedback, motor running status, interlock signal termination
• Petrochemical, refinery plant discrete equipment status monitoring and safety interlock wiring
• Oil & gas, pulp & paper plant field limit switch and contact signal marshalling
• Metallurgy, water treatment equipment binary status signal collection terminals
• Legacy Experion PKS simplex DI IOTA replacement, maintenance and plant retrofits

FAQ (Frequently Asked Questions)

• Q: DI channel no feedback or status jump after installing CC-TDIL01?
  A: Confirm IOTA matches CC-PDIL01 IOM, check field contact wiring and 24VDC excitation power, inspect open wire alarm, shield grounding and ribbon cable connection.
• Q: Does Honeywell CC-TDIL01 support hot-swap replacement?
  A: Hot swap is supported. Risk assessment and LOTO lockout-tagout must be performed before replacement to avoid interlock misjudgment and plant disturbance.
• Q: What is the difference between CC-TDIL01 and CC-TDIL11?
  A: CC-TDIL01 is simplex DI IOTA; CC-TDIL11 is redundant DI IOTA for critical interlock loops requiring IOM redundancy.
• Q: What IOM card matches this IOTA?
  A: Paired with CC-PDIL01 32-channel 24VDC digital input IOM module.
• Q: Is Honeywell CC-TDIL01 (51308386-175) available for new DCS projects?
  A: This legacy Experion Series C IOTA terminal assembly is end-of-life for new installations. Only fully tested surplus and refurbished units are supplied for existing DCS system maintenance and retrofits.
