IC754CSF12CTD — GE Fanuc QuickPanel View 12" Color Touchscreen HMI
The IC754CSF12CTD is a 12-inch color touchscreen operator interface from the GE Fanuc QuickPanel View family. It is a panel-mounted HMI (Human-Machine Interface) terminal that gives operators a clear graphical window into an industrial control system, combining a bright color display with a resistive touchscreen for direct on-screen control.
Part of GE Fanuc's widely deployed QuickPanel View series (the IC754 product line), this terminal is typically connected to a PLC or controller over Ethernet or serial communications and programmed with GE's Proficy View / Machine Edition software. The "12" in the part number denotes the 12-inch display size, the C indicates color, and the T denotes the touchscreen. It remains a common spare and replacement unit for plants running existing QuickPanel View installations.
Key Specifications
| Manufacturer | GE Fanuc / General Electric (now Emerson) |
| Model / Part Number | IC754CSF12CTD |
| Product Line | QuickPanel View (IC754 series) |
| Product Type | Operator Interface Terminal / HMI |
| Display Size | 12 inch (per part-number designation) |
| Display Type | Color TFT/LCD |
| Input Method | Resistive touchscreen |
| Communications | Ethernet and serial ports (supports GE SRTP, Modbus, and other QuickPanel View drivers) |
| Programming Software | Proficy View / Proficy Machine Edition |
| Mounting | Panel-mounted (flush-mount cut-out) |
| Status | Legacy — available through spare-parts and repair channels |
Note: Exact resolution, memory, and supply-voltage figures vary between revisions and listings. Confirm the full part-number suffix and specifications against your unit or the official GE datasheet before ordering.
Product Functions
- Graphical process visualisation: Displays plant data, process graphics, and status indicators on a 12-inch color screen for at-a-glance monitoring.
- Touchscreen operator control: The resistive touchscreen lets operators press buttons, enter setpoints, and navigate screens directly, reducing dependence on physical panel hardware.
- Alarm & event management: Shows alarm messages and event logs, helping operators respond to abnormal conditions promptly.
- Data trending & logging: Displays trends of process variables and supports data recording for analysis and reporting.
- Multi-protocol connectivity: Communicates over Ethernet and serial links, supporting GE drivers (such as SRTP) as well as Modbus and other common protocols for integration with a range of controllers.
- Application programming: Screens and logic are built in Proficy View / Machine Edition, allowing customised operator interfaces for each process.
- Rugged panel design: Built for industrial environments, resisting vibration, dust, and temperature swings typical of the factory floor.
Application Scenarios
- Power generation & utilities: Operator interfaces for turbine, boiler, and auxiliary plant control.
- Oil & gas: Process monitoring and control at onshore and offshore facilities.
- Water & wastewater treatment: Pump, valve, and treatment-process operation at local panels.
- Manufacturing & production lines: Machine-level HMI for operation, monitoring, and changeover.
- Chemical, pulp & paper, metals: Continuous-process supervision where reliable operator interfaces are essential.
- Legacy system maintenance: Replacement or spare HMI for plants running existing QuickPanel View installations.
Frequently Asked Questions
What is the IC754CSF12CTD?
It is a 12-inch color touchscreen operator interface terminal from the GE Fanuc QuickPanel View (IC754) family, used as an HMI for industrial control systems.
Which systems is it compatible with?
It communicates with a wide range of PLCs and controllers via Ethernet and serial connections, and supports common GE and Modbus drivers. Confirm your specific controller and protocol against the QuickPanel View driver list before ordering.
What software is used to program it?
It is programmed with GE's Proficy View or Proficy Machine Edition software, which is used to design the operator screens and configure communications.
Is it a touchscreen unit?
Yes. The "T" designation in the part number and the "CSF" series indicate a color touchscreen model, allowing direct on-screen operation.
Is the IC754CSF12CTD still manufactured?
It is a legacy product. Existing stock, refurbished units, and repair services are generally available through industrial automation spare-parts suppliers. Contact your supplier for current availability and lead time.
What should I verify before ordering a replacement?
Match the complete part number and suffix, confirm the panel cut-out dimensions, connector type, and the software/firmware version used by your existing project. Providing a photo of your current unit to the supplier helps ensure a correct match.
