B&R 5AP1130.156C-000 Automation Panel 15.6" (AP1000 Series)
The B&R 5AP1130.156C-000 is an Automation Panel from B&R's AP1000 series featuring a 15.6" Full HD (1920 × 1080) display. As part of B&R's modern HMI panel range, it serves as the operator interface in a B&R control system, displaying machine and process information and receiving operator input via touch. Automation Panels are designed to work with B&R's PC-based control platforms and deliver clear, high-resolution visualisation for industrial machines and production lines.
- B&R Automation Panel, AP1000 series
- 15.6" display, Full HD 1920 × 1080
- Modern HMI operator interface
- Designed for B&R control systems
- Order number: 5AP1130.156C-000
Key Features & Functions
Full HD Visualisation
A 15.6" 1920 × 1080 display provides sharp, high-resolution presentation of machine states, process values, trends and alarms.
Generous Screen Size
The 15.6" diagonal offers a large operator surface, ideal for complex HMI screens requiring multiple values and controls at once.
AP1000 Platform
Part of B&R's AP1000 Automation Panel family, designed for integration with B&R's PC-based automation and visualisation systems.
Industrial HMI Design
Built for flush panel mounting in machine and cabinet doors, with the durability required for continuous industrial operation.
Flexible System Integration
Connects to B&R controllers and PCs over standard interfaces, supporting distributed operator stations across a machine or line.
Modern Operator Experience
High-resolution display and touch input support contemporary, information-rich HMI design for operators and maintenance staff.
Technical Specifications
| Model / Order Number | 5AP1130.156C-000 |
|---|---|
| Brand | B&R (Bernecker & Rainer) |
| Product Family | Automation Panel (AP1000 series) |
| Display Size | 15.6" |
| Resolution | 1920 × 1080 (Full HD) |
| Device Type | HMI operator panel |
| Mounting | Panel mount |
Source note: The 15.6" Full HD display specification is based on the B&R Automation Panel AP1000 series documentation for the 15.6" model variant. Exact touch technology, interface set, supply voltage, power consumption and environmental ratings must be confirmed against the official B&R datasheet for order number 5AP1130.156C-000 before ordering.
Typical Application Scenarios
- Machine HMI: main operator interface for production, packaging and special-purpose machinery.
- Production Line Visualisation: line-wide displays for status, throughput and alarms.
- Process Control: visualisation of process values and parameters in process industry applications.
- Distributed Operator Stations: multiple panels networked across a plant or machine group.
- System Upgrades & Retrofits: modernising existing B&R HMI installations with a larger Full HD panel.
Frequently Asked Questions
What is the B&R 5AP1130.156C-000?
It is a B&R Automation Panel from the AP1000 series with a 15.6" Full HD (1920 × 1080) display, used as the HMI operator interface in B&R control systems.
What display size and resolution does it have?
The panel features a 15.6" display with Full HD 1920 × 1080 resolution.
Which series does it belong to?
It is part of B&R's AP1000 Automation Panel series, the company's range of modern HMI operator panels for industrial machinery.
How is it mounted?
It is designed for panel mounting into control cabinet doors and machine panels. Confirm the exact cut-out dimensions against the official B&R datasheet.
Which interfaces does it provide?
Interface configuration varies by variant. Please verify the exact interface set for order number 5AP1130.156C-000 in the official B&R datasheet.
Where can I find the official datasheet?
Official technical documentation is available from B&R Industrial Automation and authorized distributors. Verify all specifications there before purchase.
