Allen-Bradley 6177R-MMPXP VersaView 6177R 750R Performance Machine Mount Non-Display Industrial PC

Product Brief Description

The 6177R-MMPXP is a high-reliability non-display industrial box PC independently developed by Rockwell Automation (Allen-Bradley), belonging to the classic VersaView 6177R series industrial control computer product line. As the key industrial-grade computing host specially designed for large-scale industrial automation scenarios that have extremely strict requirements for industrial monitoring data processing and system operation continuity, it is widely deployed in heavy-duty industrial scenarios such as automobile manufacturing production lines, petrochemical DCS control systems, large-scale logistics automated sorting stations and other industries that have extremely strict requirements for industrial computer operation stability and long-term continuous operation capability, responsible for running FactoryTalk View SE monitoring software, OPC data server, industrial data acquisition and other core industrial software, ensuring that the industrial monitoring system can continuously and stably operate without interruption during long-cycle uninterrupted production, providing the most fundamental high-reliability computing guarantee for the stable operation of large-scale industrial automation systems.

Core Technical Specifications

• Manufacturer: Rockwell Automation (Allen-Bradley), original industrial control computer grade production standard
• Product Category: VersaView 6177R series 750R Performance machine mount non-display industrial PC, official part number 6177R-MMPXP
• Physical Parameters: Compact box-type machine wall-mounted installation design, net weight about 3.2kg, IP20 protection grade, fully compliant with industrial anti-vibration and anti-electromagnetic interference standards
• Electrical Parameters: AC 100~240V wide voltage universal power supply, 50/60Hz working frequency, maximum power consumption 120W, with built-in power supply overvoltage and overcurrent protection circuit
• Performance Parameters: Adopting Intel 32-bit industrial processor, main frequency up to 3.0GHz, the industrial software operation response speed is more than 2 times that of ordinary commercial industrial computers, which can efficiently run multiple sets of industrial monitoring software and data acquisition services at the same time
• Memory Configuration: 2GB DDR3 RAM, 160GB SATA mechanical hard disk, which can fully meet the large-capacity industrial monitoring software operation and long-term historical data recording demands
• Expansion and Interface Capability: 4 independent expansion slots (1 PCI, 1 PCIe x16, 1 PCIe x4, 1 PCIe x1), equipped with 2 independent Gigabit Ethernet ports, 2 DVI video output interfaces (DVI-1 can be converted to VGA), 7 USB 2.0 ports, 2 USB 3.0 ports, 2 RS232 serial ports, 1 parallel port, PS/2 keyboard and mouse interface, which can seamlessly realize data interconnection with Rockwell ControlLogix series PLC systems, on-site industrial instruments and upper monitoring platforms
• Operating Environment: 0°C to +50°C industrial working temperature range, 5%-95% non-condensing relative humidity, mean time between failures (MTBF) as high as 150,000 hours

Key Core Functions

• Industrial Specialized Performance Package Configuration: The module adopts Rockwell exclusive industrial-grade hardware optimization design, the motherboard circuit has been specially filtered and anti-interference processing, which can stably operate in the industrial site strong electromagnetic interference environment, and the system crash rate is less than 0.1% under long-term continuous operation, far lower than that of ordinary commercial industrial computers.
• Rich Industrial Expansion Capability: The 4 independent expansion slots can be installed with various industrial communication cards, data acquisition cards and motion control cards according to the actual on-site demand, which can easily expand the number of industrial communication interfaces and data acquisition channels, effectively reducing the system hardware investment cost.
• Perfect Rockwell System Compatibility: The module is pre-installed with Windows XP Professional SP3 operating system, which is fully compatible with all versions of Rockwell FactoryTalk View SE, RSLogix 5000 and other industrial software, no additional driver adaptation is needed, and it can seamlessly connect with the existing Rockwell PLC control system and monitoring platform, which can be directly used as spare parts for the maintenance and replacement of old industrial monitoring systems that have been in operation for many years, effectively extending the service life of the old industrial automation system.
• Dual Redundant Network Port Design: The module is equipped with two independent Gigabit Ethernet ports, which can realize dual network redundant connection with the industrial control network, automatically complete seamless non-disturbing switching within 10ms when one network link fails, the industrial data transmission will not be interrupted at all, completely avoiding the huge economic loss caused by the monitoring system network interruption and the production line unexpected shutdown.
• Easy Installation and Maintenance Design: The machine wall-mounted installation design does not occupy the standard cabinet installation space, the interface layout is clear and reasonable, maintenance personnel can quickly complete the disassembly and replacement operation of the industrial PC without modifying a large number of internal wiring of the industrial control system, which greatly shortens the system fault recovery time and reduces the production loss caused by equipment shutdown.

Typical Application Scenarios

• Automobile manufacturing industry: Automobile body-in-white welding workshop industrial monitoring system, responsible for running FactoryTalk View SE monitoring server and OPC data server.
• Petrochemical industry: Large-scale refinery DCS control system monitoring host, realizing stable and reliable operation of the whole plant process parameter monitoring software.
• Logistics handling industry: Large automated sorting station industrial data acquisition server, realizing high-speed and stable data transmission of the whole sorting line control system.
• Machinery processing industry: Large CNC machine tool production line monitoring system, realizing stable and reliable operation of the equipment operation state monitoring software.
• Industrial transformation and upgrading projects: Spare parts replacement and system maintenance of old Rockwell industrial monitoring systems that have been in operation for many years in various industrial sites.

Installation and Maintenance Guidelines

• Strict anti-static protection must be implemented before installation: operators must wear a reliably grounded anti-static wrist strap to avoid static electricity damaging the precision processor and memory components on the motherboard.
• The industrial control network wiring must strictly follow the Rockwell industrial automation system wiring specifications, use dedicated double-shielded industrial Ethernet cables, and the shielding layer must be reliably double-ended grounded to effectively avoid network signal interference and data loss.
• After installation, perform full function test and system stability test of the industrial PC through the dedicated Rockwell industrial software, confirm that the software operation function, network communication function, expansion card function and fault diagnosis function of the industrial PC fully meet the system design requirements.
• Regularly check the operation state of the industrial PC during daily operation, regularly clean the dust accumulated on the surface of the heat dissipation fan and heat sink every 1 year, and replace the aging mechanical hard disk in time, which can effectively extend the service life of this industrial PC to more than 10 years.

Market and Supply Status

As a classic supporting non-display industrial PC product of Rockwell VersaView 6177R series, 6177R-MMPXP was officially discontinued by Rockwell on December 31, 2021, and there is no official new product supply. Multiple professional industrial automation spare parts suppliers in Xiamen, Fujian have sufficient spot stocks of original refurbished and used disassembled units. The product comes with 365 days of quality assurance service, which can be delivered quickly within 1-3 working days, fully meeting the spare parts replacement and maintenance demands of old Rockwell industrial monitoring systems that have been in operation for many years around the world.
