WOODWARD 5484-803 MicroNet CPU Processor Module

Product Brief Description

Woodward 5484-803 is the main CPU processor board for MicroNet turbomachinery control systems. It executes the core control logic, speed governing, protection sequencing and interlock calculations for turbines and compressors. The module communicates with chassis I/O boards through the high-speed backplane and supports multiple communication links for HMI and DCS interface. It is a rack plug-in card used in MicroNet chassis, widely stocked as spare part for industrial prime mover control cabinet maintenance and retrofits.

Product Features & Functions

• Main processing unit to run all turbine control, protection and sequence logic
• High-speed backplane communication to read I/O modules and send control outputs
• Supports speed governing, load control, interlock logic and trip protection algorithms
• Multiple communication ports for HMI, Modbus TCP/RTU and peer-to-peer controller links
• Non-volatile memory to store application firmware, user parameters and event history
• Powerful event recorder for alarms, trips and trending data for post-fault analysis
• Onboard LED indicators for run status, fault, communication and health diagnostics
• Conformal coated PCB, designed for rugged industrial cabinet environments
• Supports simplex configurations, compatible with Woodward GAP programming software

Application Scenarios

• Steam turbine and gas turbine control systems
• Centrifugal compressor control skids for oil & gas industry
• Cogeneration CHP plants and captive power generation stations
• Refinery and chemical plant turbomachinery control cabinets
• Legacy MicroNet system spare replacement, upgrade and retrofit projects
