ABB 086407-502 Power Supply Module for AC 800M / 800xA DCS

Product Brief Description: ABB 086407-502 is a hot-swappable power supply module for ABB AC 800M controller (PM851, PM856, PM860, PM864, PM866) and System 800xA DCS platform. It provides regulated DC power for the controller CPU, backplane and I/O modules, supports parallel redundant configuration for critical process control systems. The universal wide-range AC/DC input design ensures stable power conversion and protection against overload, short-circuit and over-temperature faults. It is widely used as spare replacement part in power, chemical and oil & gas control cabinets.

Product Features

• Universal input: 85–264V AC or 100–370V DC, auto-sensing
• Regulated 24VDC output, high efficiency fanless convection cooling
• Hot-swap capable for replacement without system shutdown in redundant setup
• Supports N+1 parallel redundancy to enhance system reliability
• Built-in protections: overvoltage, overcurrent, short-circuit, thermal shutdown
• Front panel LED indicators for power OK and fault diagnostic status
• Reinforced isolation (3kV AC) between input and output side
• Slide-in rack mounting, directly fits AC800M controller baseplate slot
• Wide operating temperature for heavy industrial cabinet environments
• CE and RoHS compliant for process automation applications

Application Scenarios

• Power plant DCS and auxiliary control systems
• Chemical, petrochemical and oil & gas process control cabinets
• Water treatment and wastewater plant 800xA automation systems
• Mining and heavy industry distributed control systems
• Critical manufacturing production line redundant control platforms
