ABB RHD250‑10 Contrac Electric Part‑Turn Rotary Actuator

Product Description

The RHD250‑10 is a rugged intelligent modulating rotary actuator manufactured by ABB Contrac series. It delivers a rated torque of 250 Nm with an adjustable operating speed from 10 s to 900 s for a 90‑degree stroke. It adopts a stall‑proof mechanical gearbox design and requires no torque or position‑dependent cut‑off. The actuator must work with separate microprocessor‑controlled electronic units EBN853 or EBS852 for signal processing. It is built with a heavy‑duty metal housing, mechanical limit stops and a manual handwheel for emergency operation, suitable for continuous long‑term operation under humidity, dust and vibration in process plants. It is widely supplied as spare replacement equipment for valve automation systems.

Product Functions

• Continuous modulating positioning and three‑step on/off control for dampers, ball valves and butterfly valves
• Stall‑proof gearing prevents mechanical damage during valve jamming without torque switch protection
• Local handwheel operation for manual emergency control during power failure
• Mechanical adjustable limit stops to define the opening and closing travel range
• Compatible with 4‑20mA analog control signal, HART and major industrial fieldbus communication via matched electronic control unit
• Built‑in position feedback, load torque monitoring and comprehensive self‑diagnosis of motor and gear condition
• Local status indication and fault alarm output for on‑site maintenance inspection

Application Scenarios

• Power plant boiler air dampers, flue gas and combustion gas flow regulation valves
• Water and wastewater treatment plants for butterfly valve and sluice gate automatic control
• Oil refinery, chemical and natural gas pipeline rotary valve regulating and shut‑off control
• Pulp & paper, cement and metallurgy process gas and medium flow control loops
• District heating and thermal energy station pipeline flow and pressure regulation
• Spare replacement and retrofit of aging ABB Contrac RHD series valve actuators
