1. Product Description

A06B-6110-H055 is a 3-axis integrated servo amplifier of FANUC αi series, model designation αiSV 12/12/12, original made in Japan. It is compatible with legacy FANUC CNC systems including 0iA, 0iB, 16i, 18i and 21i-B series.

Model code breakdown: - A06B: General prefix for FANUC servo drive modules - 6110: Series code for αi triple-axis servo amplifier unit - H055: Hardware specification code representing 12A rated output per axis

This all-in-one triple-axis unit drives X/Y/Z three feed axes simultaneously in one compact module. It communicates with CNC main unit via FSSB optical fiber bus and relies on matched PSM power supply modules (A06B-6079 series) to supply DC bus voltage ranging from 283V to 330V.

Core Electrical Specifications: 1. Continuous rated current per axis: 12A; peak current 36A (max 3 seconds) 2. Encoder compatibility: 17bit / 22bit αi serial encoders 3. Communication: Dual-channel FSSB fiber bus, supporting ring topology multi-drive expansion 4. Control algorithm: HRV3+ high-response vector control, built-in vibration suppression and AI contour control 5. Input power standard: 3-phase 200V AC (converted to DC bus by PSM power unit) 6. Operating temperature: 0℃ ~ 55℃, forced air cooling via cabinet fan

2. Core Product Functions

• Independent 3-Axis Servo Motion Control Single module integrates three independent power drive circuits for X/Y/Z feed axes, with separate closed-loop control of current loop, speed loop and position loop, reducing cabinet wiring and installation footprint.
• FSSB High-Speed Optical Servo Bus Optical fiber transmission eliminates EMI interference from inverters and contactors, ensures high multi-axis synchronization and supports ring network cascading for 4th/5th axis expansion.
• HRV3+ High-Precision Machining Control High-bandwidth current loop suppresses corner overshoot during high-speed cutting, eliminates machine resonance with adaptive vibration suppression algorithm for mold and precision machining.
• Full Hardware Self-Diagnosis & Protection Real-time monitoring of output overcurrent, DC bus overvoltage/undervoltage, heatsink overtemperature, encoder disconnection and motor overload. The drive cuts off power instantly and sends alarm codes to CNC once faults are detected.
• Wide Compatibility with αi Servo Motors Matches 0.5kW ~ 4kW αiS / αiF feed servo motors, supporting both absolute and incremental encoder feedback modes.
• Nano Interpolation for Ultra-Fine Machining Cooperates with CNC system to realize nanometer-level interpolation and smooth tiny line segments, ideal for optical parts and precision die machining equipment.
• Modular Rack Mount Design Standard pluggable industrial rack structure, enabling quick replacement after power-off to minimize equipment downtime during maintenance.
• Multi-Layer Electrical Safety Protection Independent short-circuit cut-off, overcurrent current limiting and soft-start DC bus buffer for each axis, preventing impact damage to power modules and machine mechanical structures.

3. Typical Application Scenarios

• Vertical Machining Centers (VMC) X/Y/Z feed axis drive for 3-axis milling machines, standard servo unit for 0i-MB and 18i-B CNC systems.
• CNC Lathes & Turn-Mill Composite Machines 3-axis control for X/Z feed axes plus turret C-axis.
• Precision Mold Engraving & Graphite Milling Machines High-speed high-precision cutting applications, HRV3 algorithm eliminates machining vibration marks.
• Semiconductor Packaging Equipment & Custom CNC Automation Stages Multi-axis precision positioning table driving.
• Retrofit Spare Parts for Legacy FANUC Machine Tools Original replacement component for αi series equipment manufactured from 2004 to 2009.

4. Common Faults & Troubleshooting Solutions

5. Import & Supporting Document Information

1. Required documents: Certificate of Origin (COO), Factory Certificate of Conformity (COC) 2. SDS/MSDS safety data sheet for industrial electronic control board 3. Factory test report and calibration records 4. HS Code: 85437090 Servo Motor Controllers 5. Country of Origin: Japan; Gross Weight: Approx. 3.2kg 6. Lead Time: In stock 1~3 working days; Forward order 4~8 weeks 7. Matching spare parts: Cooling fan, FSSB optical fiber, servo power cable, encoder feedback cable
