1. Product Description

The 2097‑V34PR5 and 2097‑V34PR5‑LM are compact single‑axis AC servo drives belonging to Rockwell Automation Allen‑Bradley Kinetix 300 series motion control family.

           2097‑V34PR5: Standard base model, 400V class three‑phase input, continuous output current 34A, rated for 15kW servo motor matching, standard digital encoder feedback interface.

           2097‑V34PR5‑LM: Low‑EMI enhanced variant of the V34PR5 base unit, integrated built‑in line filter and optimized power snubber circuit to reduce conducted & radiated electromagnetic interference; fully pin‑to‑pin mechanical and electrically compatible with the standard 2097‑V34PR5, supporting direct drop‑in replacement without cabinet modification.

           Both models adopt wall‑mount compact metal housing, support single‑cable servo motor connection, integrated safe torque off (STO) safety function, and native EtherNet/IP motion bus communication for seamless connection with Logix 5000 series PLC controllers.

2. Core Product Functions

• High‑Performance Servo Control: Support velocity, position, torque closed‑loop vector control, 16kHz high‑speed current loop bandwidth for precise high‑dynamic positioning.
• Dual Feedback Compatibility: Accept incremental encoders, multi‑turn absolute encoders; single cable motor feedback wiring simplifies cabinet wiring layout.
• EtherNet/IP Real‑Time Motion Bus: Native CIP Motion protocol, synchronized multi‑axis motion coordination, direct tag mapping with Studio 5000 Logix Designer.
• Safe Torque Off (STO) SIL2 Safety Circuit: Hardware‑based motor power cut‑off function, meets IEC 61508 SIL 2 machine safety requirements.
• Built‑in Motion Programming: Embedded electronic gearing, cam profiling, homing routines, and position limit logic to reduce PLC program load.
• Multi‑Layer Hardware Protection: Overcurrent, overvoltage, undervoltage, motor overload, drive overtemperature, output short‑circuit, encoder loss fault detection with fault code logging.
• 2097‑V34PR5‑LM Exclusive Low‑EMI Function: Integrated EMC line filter suppresses power line harmonic noise, eliminates external filter hardware cost, complies with IEC 61800‑3 Category C2 EMC standards out‑of‑box.
• Flexible Digital/Analog I/O: Configurable digital input/output terminals for external start/stop, home switch, fault reset, and analog speed/torque setpoint signals.

3. Typical Application Scenarios

• Packaging Machinery: Carton filling, labeling, sealing, vertical form fill seal (VFFS) machine main & auxiliary axis positioning control.
• Material Handling & Conveyors: High‑speed sorting conveyors, palletizing robots, automated warehouse shuttle car servo axes.
• CNC & Processing Equipment: Small CNC milling, laser cutting, plasma cutting, printing press register correction axes.
• Food & Beverage Automation: Bottle filling lines, rotary packaging turrets, conveyor speed synchronization drives.
• Textile Machinery: Spinning frames, weaving looms, fabric cutting and winding precise tension control axes.
• Electronic Assembly Lines: SMT pick‑and‑place machines, PCB transport conveyors, automated test fixture positioning.
• Plastic Molding Auxiliary Equipment: Injection mold extractors, extruder haul‑off puller speed regulation systems.
• EMI‑Sensitive Workshop (Preferred for 2097‑V34PR5‑LM): Laboratories, medical device manufacturing, precision inspection equipment where electrical noise interference must be minimized.
