• Part No.: IS230PCAAH1B | Brand: General Electric | Series: Speedtronic Mark VIe
• Product Type: Core Analog I/O Module (PCAA)
• Analog Input Channels: 25 multi-functional isolated analog inputs
• Supported Input Signals: Thermocouple, 4–20mA, 0–10VDC, LVDT excitation, seismic vibration, pulse frequency
• Output Signals: Servo coil drive output, 4–20mA analog control output
• Measurement Accuracy: 0–10VDC ±0.50%; LVDT monitoring ±1.00%; Servo output ±3.50%
• Communication Interface: Dual 10/100Mbps RJ45 Ethernet IONet ports
• Rated Power Supply: 28 VDC ±5% industrial power
• Control Frame Rate: 10ms / 40ms deterministic real-time acquisition
• Operating Temperature: -30°C ~ +65°C | Storage Temperature: -40°C ~ +85°C
• Physical Dimension: 33.02cm (H) × 17.8cm (W) | Surface-mount SMT technology
• Compatible Terminal Boards: TCAS, TCAT analog signal terminal boards
• Certifications: CE, UL, CSA, industrial EMC anti-interference compliance

• Multi-type universal analog signal processing, integrates temperature, displacement, vibration and flow signal acquisition for full turbine monitoring
• High-precision 16-bit AD/DA conversion, stable sampling accuracy with low temperature drift under fluctuating cabinet temperature
• Dual redundant IONet Ethernet communication, supports hot backup data transmission to avoid single communication point failure
• Full compatibility with simplex, dual and TMR triple redundant safety control architectures for high-reliability turbine protection systems
• Built-in complete channel self-diagnosis function, front panel LED indicators for quick fault positioning of open circuit, short circuit and signal abnormalities
• Modular rack plug-in design, matched with TCAT/TCAS terminal boards for convenient wiring, disassembly and field maintenance replacement
• Industrial wide temperature and anti-vibration design, long-term stable operation in harsh power plant control cabinet environments

• Thermal Power Plant: Gas turbine & steam turbine unit control, combustion monitoring and valve servo regulation
• Oil & Gas: Onshore and offshore gas turbine power generation, pipeline compressor unit control systems
• Petrochemical: Heavy-duty turbine drive control for refinery process equipment
• Combined Cycle Power Station: Multi-turbine coordinated monitoring and safety interlock control
• Industrial Heavy Machinery: Large high-speed turbine and blower precision analog monitoring systems

FAQ (Frequently Asked Questions):

Q:  new or refurbished?

A: We offer both original new and tested refurbished options. Please contact us for stock availability.

Q: How long is the delivery time?

A: Stock items can be shipped within 1-3 working days. Lead time for out-of-stock items is 2-4 weeks.

Q: Can you provide technical support after purchase?

A: Yes, our engineers are available to assist with installation, configuration, and troubleshooting.
