GE WESDAC D20ME Industrial Control Module & WESDAC D20PS Power Supply Module
The GE WESDAC D20ME and WESDAC D20PS are complementary industrial automation components designed to deliver reliable control and stable power for critical industrial systems. As part of GE’s WESDAC product line—renowned for ruggedness in harsh industrial environments—the D20ME serves as a high-performance modular controller, while the D20PS provides dedicated, industrial-grade power. Together, they form a cohesive solution for process control, data acquisition, and system coordination in manufacturing, energy, and infrastructure applications.
GE WESDAC D20ME Industrial Control Module
Key Technical Specifications
- Processor: 32-bit Freescale 68030 microprocessor (40 MHz) for deterministic control
- Memory: 16 MB SDRAM (user-configurable), 2 MB Flash (firmware), 2 MB SRAM (512 KB battery-backed for data retention)
- I/O Capability: 16 configurable channels (8 digital I/O, 8 analog I/O) with signal conditioning
- Communication Protocols: Modbus RTU, Profibus DP, Ethernet/IP; RS-485 and Ethernet ports for network integration
- Operating Voltage: 24 VDC (powered by D20PS or compatible industrial power supply)
- Operating Environment: -20°C to +70°C (-4°F to 158°F); 5-95% humidity (non-condensing); IP65 protection rating
- Dimensions: 300 mm x 200 mm x 100 mm; Panel or DIN rail mounting options
Software Compatibility: GE Proficy Machine Edition, iFIX for programming and monitoring
Core Features
Precision Process Control: Executes real-time control logic with low latency, supporting sequential, regulatory, and discrete control applications.
Flexible I/O Expansion: Configurable channels adapt to digital sensors, analog transducers, and actuators, enabling customization for diverse industrial tasks.
Seamless Network Integration: Supports industry-standard protocols for communication with SCADA systems, DCS, and other automation components.
Rugged Design: Dustproof, waterproof (IP65), and vibration-resistant construction ensures reliability in harsh factory or field environments.
GE WESDAC D20PS Industrial Power Supply Module
Key Technical Specifications
- Input Voltage: 100-240 VAC (wide-range AC input) or 120-370 VDC (optional DC input)
- Output Parameters: 24 VDC nominal output, 10 A continuous current, 240 W maximum power
- Protection Features: Short-circuit, overcurrent, overvoltage, and overtemperature protection
- Efficiency: >85% typical (energy-efficient operation to reduce power consumption)
- Operating Environment: -10°C to +60°C (14°F to 140°F); 10-90% humidity (non-condensing)
- Physical Design: Aluminum housing (IP20 rating); 100 mm x 80 mm x 25 mm; 0.5 kg net weight
- Compliance: IEC 60950-1, UL 508, CE certified for global industrial standards
Mounting: DIN rail (35 mm) or panel-mount, compatible with standard control cabinets
Core Features
Stable Power Delivery: Regulated 24 VDC output with low ripple and noise, ensuring consistent performance for the D20ME and connected I/O devices.
Wide Input Compatibility: Accepts global AC voltages (100-240 VAC) for international deployment, eliminating the need for voltage converters.
