Siemens 3WL1110-3EB36-4GA4 Circuit Breaker Origina New In Stock

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

Product: 3WL1110-3EB36-4GA4 – SIEMENS SENTRON 3WL Air Circuit Breaker

Germany Original 3P 1000A 690V Draw-out ACB, ETU45 LSIN, Icu=66kA, Industrial Distribution

Siemens 3WL1110-3EB36-4GA4 is a high‑performance **draw‑out air circuit breaker (ACB)** from the SENTRON 3WL series, designed for low‑voltage industrial power distribution systems. It provides reliable short‑circuit and overload protection with intelligent monitoring and communication capabilities。

Core Technical Specifications

Model: 3WL1110-3EB36-4GA4 | Brand: SIEMENS (Germany)
Series: SENTRON 3WL | Type: Draw‑out Air Circuit Breaker (ACB)
Poles: 3‑pole | Size: Size I
Rated Current (In): 1000 A | Rated Voltage (Ue): 690 V AC 50/60 Hz
Breaking Capacity: Icu=66 kA @ 500 V; Ics=66 kA; Icw=50 kA/1s
Trip Unit: ETU45 (LSIN: Long/Short/Instantaneous/Ground Fault)
Connection: Rear horizontal | Mounting: Draw‑out (with guide frame)
Operating Mechanism: Motorized/manual with spring charging (208–240 VAC/220–250 VDC)
Certification: IEC 60947‑2, CE, UL, CSA
Operating Temp: −5°C to +55°C | Storage Temp: −20°C to +70°C
Dimensions (W×H×D): 275 × 210 × 180 mm | Weight: ~28 kg

Main Functional Features

Modular design: Draw‑out structure for easy maintenance and replacement
ETU45 protection: Adjustable LSIN curves with LCD display and cubicle bus
High breaking capacity: 66 kA withstands severe short‑circuit faults
Communication ready: Supports PROFIBUS DP/Modbus RTU via optional modules
Comprehensive diagnostics: Real‑time current/voltage monitoring, fault logging
Motorized operation: Remote control with spring charging for reliable closing

Application Industries

Power Plants: Main distribution, generator feeders, auxiliary systems
Oil & Gas: Refineries, compressor stations, hazardous area power supply
Chemical & Petrochemical: Process plant main switchboards, motor control centers
Data Centers: Critical power distribution, UPS bypass, main incoming feeders
Manufacturing: Automotive, metallurgy, pulp & paper plant distribution systems

Product Picture

Global Inventory: 121 shared inventories worldwide, enabling fast delivery from overseas warehouses.

Pricing & After-Sales: Competitive prices with reliable 1-year warranty.
Customer Coverage: United States, Germany, Japan, South Korea,
UK, France, Italy, Canada, Brazil, Australia, Russia, Spain, Netherlands,
Switzerland, Sweden, Belgium, Austria, Turkey.
Product Quality: 100% original new, tested before shipment.
Discounts: Wholesale discounts available for bulk orders.

For additional inquiries, reach out to us at any time.
