PIONEER MAGNETICS PM3398B-6P-1-3P-E 80026-172-23 Switching Power Supply--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Pioneer Magnetics 80026-172-23
Industrial-Grade Switching Power Supply for Automation Systems
1. Product Overview
The Pioneer Magnetics 80026-172-23 is a high-efficiency industrial switching power supply engineered for reliable power delivery in mission-critical industrial automation, process control, and manufacturing systems. With a universal AC input (90-264V AC), configurable DC output (up to 24V DC, 20A), and 480W maximum power, it delivers stable performance in harsh industrial environments. Built with advanced power conversion technology, it features overcurrent, overvoltage, and short-circuit protection, along with an efficiency rating exceeding 85% under nominal loads. Its rugged design supports -20°C to +70°C operating temperature range, making it ideal for factory automation, robotics, and distributed control systems (DCS) requiring continuous 24/7 operation.
Key Specifications
• Model: 80026-172-23 | Brand: Pioneer Magnetics | Type: Industrial Switching Power Supply
• Input Voltage: 90-264V AC (Universal); Frequency: 47-63 Hz
• Output Voltage: Configurable up to 24V DC; Output Current: Up to 20A
• Power Output: 480W Max; Efficiency: >85% (Nominal Load)
• Protection Features: Overcurrent, Overvoltage, Short-Circuit, Over Temperature
• Form Factor: DIN-Rail Mountable; Dimensions: 120mm (H) × 80mm (W) × 150mm (D)
• Operating Temperature: -20°C to +70°C; Storage: -40°C to +85°C
• Humidity: 5-95% (Non-Condensing); Altitude: Up to 2000m
• Certifications: UL 508, CE, RoHS Compliant
• Weight: 0.85 kg; Power Connector: 3-Pin Locking (IP20 Rated)
2. Core Features
• Universal AC Input: 90-264V AC range for global industrial applications
• High Efficiency: >85% efficiency reduces energy consumption and heat generation
• Comprehensive Protection: OCP, OVP, SCP, and OTP safeguards connected equipment
• DIN-Rail Mount: Easy installation in standard industrial control cabinets
• Wide Temperature Range: -20°C to +70°C for harsh industrial environments
• Low Ripple & Noise:<50mV ripple ensures clean power for sensitive electronics
• Long Operational Life: 100,000 hours MTBF (Mean Time Between Failures)
• Hot-Swappable: Supports online replacement in redundant power systems
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Typical Applications
• Industrial Automation: PLC, DCS, and SCADA Systems Power Distribution
• Factory Robotics: Servo Motor Drives, Robot Controller Power Supplies
• Process Control: Petrochemical, Pharmaceutical, and Food & Beverage Production Lines
• Test & Measurement: Automated Test Equipment (ATE) and Data Acquisition Systems
• Telecommunications: Industrial Network Equipment and Communication Infrastructure
4. Installation & Maintenance
Installation: Mount on standard DIN-Rail; Connect AC input (L, N, PE); Wire DC output (V+, V-); Verify LED indicators (Power: Green, Fault: Red).
Maintenance: Weekly – Check LED status and output voltage; Monthly – Inspect wiring connections; Annual – Clean dust from vents, verify protection circuit functionality.
Safety Notes: De-energize before installation/maintenance; Use ESD protection; Follow Pioneer Magnetics safety guidelines; Ensure proper ventilation for heat dissipation.
