Product Description

B&R 5AP933.215C-00 | 21.5" Full HD Multi-Touch Automation Panel

Projected Capacitive HMI Panel for PPC900/2100/2200/3100 - IP65 Front, 1920×1080, LED Backlight, Industrial-Grade Durability

1. Product Overview

The B&R 5AP933.215C-00 is a 21.5-inch Full HD (1920×1080) automation panel with projected capacitive multi-touch (PCT) technology, engineered for seamless integration with B&R industrial PCs (PPC900, PPC2100, PPC2200, PPC3100 series) via link modules. It features a 16:9 wide-screen TFT LCD with LED backlight (400 cd/m² typical brightness, 16.7M colors), delivering crisp visuals for machine monitoring, process control, and HMI interaction in harsh industrial environments. The front panel meets IP65/UL Type 4X protection for dust/water resistance, while the aluminum-coated frame ensures durability for cabinet flush mounting (landscape orientation). With 24VDC power (reverse-polarity protected), -20°C to +60°C storage temperature, and compatibility with B&R Automation Studio for HMI application development, it excels in manufacturing, packaging, food/beverage, and automotive industries requiring reliable, intuitive operator control with real-time data visualization.

B&R 5AP933.215C-00 (1).png

Key Specifications

• Model: 5AP933.215C-00 (AP933 Series, 21.5" FHD Multi-Touch Automation Panel)

• Type: Industrial HMI Panel (Display + Projected Capacitive Multi-Touch)

• Display: 21.5" TFT LCD, Full HD (1920×1080, 16:9), LED backlight, 16.7M colors, 400 cd/m² (typ)

• Touch Technology: Projected Capacitive (PCT), multi-touch (2-point), >90% light transmittance, scratch-resistant glass

• Mounting: Landscape flush mounting (cabinet), compatible with B&R link modules for PPC900/2100/2200/3100

• Protection: Front IP65 (EN 60529), UL Type 4X (indoor); Aluminum-coated frame, black finish

• Power: 24VDC (18-30VDC), ~50W max, reverse-polarity protected

• Operating Temp: 0°C to 50°C; Storage Temp: -20°C to 60°C; Humidity: 10-90% RH (non-condensing)

• Dimensions (W×H×D): 541.5mm × 333mm × 61mm (21.32×13.11×2.40 inches); Weight: ~5.5kg

• Connectivity: Via B&R link module (for PPC series); Supports USB, Ethernet, POWERLINK (via host PC)

• Software: Compatible with B&R Automation Studio for HMI programming, visualization, and diagnostics

• Certifications: CE, UL 508, EN 60529 (IP65), IEC 61010-1 (safety), IEC 61326-1 (EMC)

B&R 5AP933.215C-00 (6).png

2. Core Features

• Projected Capacitive Multi-Touch: 2-point PCT technology for intuitive gestures (swipe, zoom, tap) with >90% light transmittance and scratch-resistant glass.

• Full HD Visualization: 1920×1080 resolution, 16.7M colors, and 400 cd/m² brightness for clear process monitoring in bright industrial environments.

• Seamless PPC Integration: Dedicated link modules for B&R PPC900/2100/2200/3100 series, enabling plug-and-play HMI-PC connectivity.

• Industrial-Grade Protection: IP65 front panel (dust-tight, water-jet resistant) and aluminum frame for durability in harsh factory conditions.

• Flexible Power & Environmental Tolerance: 18-30VDC input (reverse-polarity protected); 0°C to 50°C operating, -20°C to 60°C storage temperature.

• Easy Programming: Compatible with B&R Automation Studio for custom HMI application development, data logging, and alarm management.

• Cabinet-Friendly Design: Landscape flush mounting, compact profile (61mm depth) for space-efficient control cabinet installation.

B&R 5AP933.215C-00 (5).png

YMGK Purchase Information

This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.

One-Stop Global Industrial Product Procurement

Sales Manager: KI MI

WeChat: 18059884790

WHATSAPP: +86 18059884790 (Click to add)

Email: plc66@qq.com

Global Inventory: 121 shared inventories worldwide, enabling direct procurement
from overseas warehouses for faster delivery.
Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
Customer Coverage: Serving clients across United States, Germany, Japan,
South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia,
Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
Product Quality: All items are brand new and original. Spare parts include a 1-year warranty,
and all products are tested and certified.
Discounts: Contact us for bulk-order discounts. We also offer further price adjustments
if you receive lower quotes for identical products from other suppliers.

For additional inquiries, reach out to us at any time.

All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders.

3. Typical Applications

• Manufacturing: Machine tool HMI for CNC control (axis positioning, tool management, alarm monitoring via multi-touch gestures).

• Packaging Machinery: Production line status visualization, parameter adjustment (e.g., sealing temperature, conveyor speed) and recipe management.

• Food & Beverage: Cleanroom-compliant HMI for filling/packaging lines (IP65 front resists washdowns); batch process monitoring with real-time data trends.

• Automotive: Assembly line control (robot status, torque monitoring, error diagnostics) with intuitive multi-touch operation for fast operator response.

• Pharmaceutical: GMP-compliant process visualization (temperature, pressure, flow) with audit trail logging via Automation Studio integration.

B&R 5AP933.215C-00 (2).png

4. Installation & Maintenance

Installation: Flush-mount in control cabinet (landscape); secure with mounting brackets. Connect to B&R PPC via link module (power/communication integrated). Wire 24VDC power (reverse-polarity protected); ensure panel front is sealed to maintain IP65 protection.

Configuration: Use B&R Automation Studio to design HMI screens, map PLC tags (I/O, diagnostics), configure multi-touch gestures (zoom, scroll), and set up data logging/alarm management.

Maintenance: Weekly: Wipe front panel with lint-free cloth (avoid harsh chemicals). Monthly: Inspect link module connections and power wiring. Annual: Verify touch sensitivity and LED backlight uniformity; update Automation Studio project firmware if needed.

Fault Diagnosis: No display = Check power/link module connection or PPC host status; Touch unresponsive = Clean screen or verify touch calibration in Automation Studio; Flickering = Inspect LED backlight or power supply voltage stability.

Technical Document | B&R 5AP933.215C-00 | 21.5" Full HD Multi-Touch Automation Panel for Industrial HMI Applications
