Woodward 5501-467 | MicroNet Simplex Power Board (220VAC/VDC)
High-Voltage Simplex Power Supply for MicroNet Simplex/Plus Chassis in Industrial Control Systems
1. Product Overview
The Woodward 5501-467 is a high-voltage simplex power board designed for MicroNet Digital Control systems, dedicated to providing stable and reliable power supply for MicroNet Simplex or MicroNet Plus chassis in simplex operation mode. It supports 220 VAC/VDC input, delivers multiple regulated output voltages (core 5 VDC with high current capacity), and integrates comprehensive protection mechanisms (overvoltage, overcurrent, overtemperature) to ensure continuous operation of control systems in power generation, oil and gas, and turbine control applications. With LED status indicators for quick fault diagnosis, it is a critical power component for industrial automation systems requiring high reliability and high-voltage power input.
Key Specifications
• Manufacturer: Woodward
• Model: 5501-467
• Product Line: MicroNet Digital Control
• Product Type: Simplex Power Board (High-Voltage)
• Input Voltage: 220 VAC/VDC (180–264 VAC, 47–63 Hz)
• Output Voltage: 5 VDC (Main Output), ±15 VDC (Auxiliary)
• Max 5 VDC Output Current: 32 A @ 55°C, 28 A @ 60°C, 22 A @ 65°C
• Input Power (Simplex Chassis): 1062 VA (Max), 5.9 A (Max Input Current)
• Input Power (Plus Chassis): 1250 VA (Max), 6.7 A (Max Input Current)
• High Voltage DC Hold-up: 7 ms @ 225 VDC
• Operating Temperature: 0°C to 55°C
• Storage Temperature: -40°C to 105°C
• Mounting: MicroNet Simplex / Plus Chassis
• LED Indicators: OK, Input Fault, Power Supply Fault, Overtemperature Fault
• Certifications: CE, UL Compliant
2. Core Features
• High-Voltage Compatibility: Supports 220 VAC/VDC input, suitable for high-voltage industrial power environments.
• Chassis Versatility: Works with MicroNet Simplex/Plus chassis, but operates exclusively in simplex mode.
• High Current Output: 5 VDC output up to 32 A (55°C), meeting high-power system requirements.
• Comprehensive Protection: Overvoltage, overcurrent, overtemperature protection for system safety.
• Visual Fault Diagnosis: Four LED indicators for quick identification of power/thermal/input faults.
• High Voltage DC Hold-up: 7 ms @ 225 VDC, ensuring transient power stability.
3. Typical Applications
• Power Generation: Provides power for MicroNet control systems in gas/steam turbine, generator set control.
• Oil & Gas: Supports control systems for pipeline compressors, refinery process automation, and wellhead control.
• Industrial Turbines: Powers simplex MicroNet systems for marine, industrial turbine speed and load control.
• Manufacturing Automation: Supplies stable power to MicroNet-based production line control systems.
• Water & Wastewater: Supports simplex control systems for pump stations, valve control, and treatment processes.
4. Installation & Maintenance
Installation: Insert into MicroNet Simplex/Plus chassis; connect 220 VAC/VDC input; verify chassis compatibility (simplex operation only); secure board with locking clips.
Maintenance: Regularly check LED status for faults; inspect input power connections for tightness/corrosion; monitor ambient temperature to avoid overtemperature shutdown.
Fault Diagnosis: Use LED indicators to locate issues (OK=normal; Input Fault=voltage out of range; PS Fault=output failure; Overtemp=thermal overload); replace faulty board or correct power input as needed.
