GE 362A1052P104 RS-FS-9001 UV Flame Sensor--KIMI
  • Warehouse: Spot
  • Warranty: 365 days
  • Quality: Original module
  • Condition: New
  • Shipping method: Courier delivery

  • Contact person: LI MING
  • Contact number: +86 18059884790
  • WeChat:18059884790
  • E-mail: plc66@qq.com

Product Description


GE 362A1052P104 RS-FS-9001 UV Flame Sensor
UV Flame Detection for Gas Turbines, Boilers & Industrial Combustion Systems
1. Product Overview

The GE 362A1052P104 (also known as RS-FS-9001) is a UV flame sensor manufactured by GE Reuter Stokes (now part of Baker Hughes). It is a two-wire, silicon carbide (SiC) UV flame detector that monitors ultraviolet radiation emitted during combustion to detect flame presence in gas turbines, industrial boilers, and furnaces. With a 4-20 mA output signal, self-checking circuitry, and hazardous area certifications, it provides reliable flame monitoring for safety-critical applications, enabling rapid shutdown in case of flame loss and preventing unburned fuel accumulation. Its side-mounted design, wide operating temperature range, and IP68 protection make it suitable for harsh industrial environments, ensuring continuous and safe operation of combustion systems.


GE 362A1052P104 RS-FS-9001 (5).png


2. Key Technical Specifications
• Brand & Model: GE 362A1052P104 (RS-FS-9001)
• Product Type: UV Flame Sensor (Silicon Carbide, SiC)
• Detection Principle: Ultraviolet (UV) Radiation (185-260 nm)
• Output Signal: 4-20 mA (Two-Wire Configuration)
• Mounting: Side-Mounted on Combustor Can
• Operating Temperature: -30°C to +150°C (-22°F to +302°F)
• Ingress Protection: IP68 (Dust-Tight, Waterproof)
• Hazardous Area Certifications: Class I Division 2, Zone 2; ATEX; IECEx
• Dimensions: 3.5 cm × 13 cm × 13.5 cm (1.38" × 5.12" × 5.31")
• Weight: Approx. 0.3 kg (0.66 lb)
• Power Supply: 12-24 VDC (Typical)
• Response Time: < 1 Second (Flame Detection)
• Self-Checking: Built-in Circuitry for Sensor Health Monitoring
• Cable Length: Compatible with Various Lengths (362A1053P Series Cables)

• Country of Origin: USA


GE 362A1052P104 RS-FS-9001 (3).png


3. Core Features
• UV Detection: Highly sensitive to UV radiation from combustion, immune to visible light interference.
• Two-Wire Design: Simplifies wiring and integration with industrial control systems.
• Self-Checking Circuitry: Monitors sensor health for early fault detection and preventive maintenance.
• Hazardous Area Rated: Suitable for use in potentially explosive environments.
• Wide Temperature Range: Operates reliably in extreme industrial conditions.
• IP68 Protection: Resistant to dust, water, and harsh weather, ideal for outdoor installations.
• Fast Response Time: Detects flame loss quickly to trigger safety shutdowns.

• Side-Mounted: Easy installation on combustor cans of gas turbines.


GE 362A1052P104 RS-FS-9001 (6).png


4. Typical Applications
• Gas Turbines: Flame monitoring in power generation and industrial gas turbine combustors.
• Industrial Boilers: Safety monitoring of flame in steam and hot water boilers.
• Furnaces: Flame detection in industrial furnaces for metal processing and heat treatment.
• Petrochemical Plants: Combustion safety in process heaters and incinerators.

• Power Plants: Safety shutdown systems for gas-fired power generation units.


GE 362A1052P104 RS-FS-9001 (4).png


5. Installation & Maintenance
Installation Steps
• Mounting: Secure the sensor to the side of the combustor can using the provided bracket.
• Wiring: Connect the two-wire cable to the sensor and the control system (ensure proper polarity).
• Calibration: Perform a flame test to verify sensor response and set the 4-20 mA output range.

• Testing: Simulate flame loss to confirm the control system receives the correct shutdown signal.


GE 362A1052P104 RS-FS-9001 (2).png

Maintenance Tips
• Regular Inspection: Check the sensor lens for dirt, debris, or damage monthly.
• Cleaning: Wipe the lens with a soft, lint-free cloth and mild cleaner if contaminated.
• Calibration Check: Verify sensor response with a test flame quarterly.
• Cable Inspection: Check for cable damage or wear; replace if necessary.
• Self-Check Monitoring: Use the control system to monitor self-check status and detect sensor faults.
Technical Document | GE 362A1052P104 RS-FS-9001 | UV Flame Sensor | Combustion Safety Monitoring
