GE Mark VIe IS200TPROS1CBB, IS230TSPRH1C & MRP680538 Core Control Modules--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
GE Mark VIe IS200TPROS1CBB, IS230TSPRH1C & MRP680538 Core Control Modules
Protection, Monitoring & Power Supply for Turbine & Industrial Automation Systems
1. Product Overview
This document covers three critical modules from GE's Mark VIe control system lineup, essential for gas/steam turbine control, protection, and power management in industrial automation. IS200TPROS1CBB is a turbine protection & monitoring I/O module, responsible for real - time parameter acquisition, safety protection logic execution, and data communication. IS230TSPRH1C serves as a specialized input module for turbine signal processing, handling various input signals and integrating with the Mark VIe control system. MRP680538 is a dedicated power supply module, providing stable and reliable power for the above - mentioned control modules and related components, ensuring the continuous and stable operation of the control system. Together, they form a core control subsystem that guarantees the safe and efficient operation of turbines in power generation, oil & gas, metallurgy and other industries.
2. Key Technical Specifications
IS200TPROS1CBB (Turbine Protection & Monitoring I/O Module)
• Brand & Model: GE IS200TPROS1CBB (Mark VIe Series)
• Product Type: Turbine - Specific Protection & Monitoring I/O Module
• Core Function: Real - time acquisition of turbine key parameters (shaft vibration, bearing temperature, rotational speed, oil pressure), safety protection logic execution, data upload
• I/O Channels: 8 Analog Inputs (4-20mA/Vibration), 4 Digital Inputs (Dry Contact), 2 Relay Outputs (Form C, for Emergency Shutdown/Alarm)
• Communication Interface: Dual - Port Ethernet (Modbus TCP/IP, SRTP), Redundant Backplane Connection
• Protection Logic: Emergency Shutdown (ESD), Overspeed Protection, Overtemperature Protection, Low Oil Pressure Protection
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Redundancy: Channel - Level & Module - Level Redundancy Supported
• Dimensions (W×H×D): 100mm × 160mm × 40mm
• Weight: Approx. 280g
• Certification: CE, UL, IEEE 1647
IS230TSPRH1C (Turbine Signal Processing Input Module)
• Brand & Model: GE IS230TSPRH1C (Mark VIe Series)
• Product Type: Specialized Turbine Signal Processing Input Module
• Core Function: Signal conditioning and processing for turbine field signals (LVDT, thermocouple, 4-20mA), I/O PACK Function
• Input Signal Type: LVDT Input, Thermocouple Input (K/J/T Type), 4-20mA Analog Input
• Signal Conditioning: Precision Amplification, Filtering, Isolation for Industrial Noise Immunity
• Backplane Interface: Mark VIe System Backplane (High - speed Data Transmission)
• Operating Temperature: 0°C to +55°C (32°F to +131°F)
• Galvanic Isolation: 2500V AC Between Channels and System
• Dimensions (W×H×D): 95mm × 150mm × 35mm
• Weight: Approx. 220g
• Certification: CE, UL, IEC 61010 - 1
MRP680538 (Dedicated Power Supply Module)
• Brand & Model: GE MRP680538
• Product Type: Dedicated Power Supply for Mark VIe Control Modules
• Core Function: Stable DC Power Supply for IS200/IS230 Series Modules
• Output Voltage: 24VDC (Main Output), 5VDC (Auxiliary Output for Logic Circuit)
• Output Current: 24VDC/10A, 5VDC/5A
• Input Voltage: 85-265VAC (50/60Hz), Wide - Range AC Input
• Protection Features: Overvoltage Protection, Overcurrent Protection, Short - Circuit Protection, Overheating Protection
• Efficiency: ≥90% (Full Load)
• Operating Temperature: -25°C to +60°C (-13°F to +140°F)
• Dimensions (W×H×D): 120mm × 180mm × 50mm
• Weight: Approx. 450g
• Certification: CE, UL, IEC 60950 - 1
3. Core Features
IS200TPROS1CBB
• Fault - Tolerant Design: Redundant configuration to ensure continuous operation even if a single channel/module fails.
• High - Speed Data Acquisition: 1ms Response Time for Critical Vibration/Temperature Signals.
• Integrated Protection Logic: Pre - programmed with turbine - specific protection algorithms to reduce engineering configuration time.
• Dual - Port Ethernet: Stable data transmission and support for predictive maintenance data upload.
IS230TSPRH1C
• Multi - Signal Compatibility: Compatible with LVDT, thermocouple and 4-20mA signals to meet diverse turbine signal acquisition needs.
• Precision Signal Conditioning: Low noise, low drift, ensuring the accuracy of measured data.
• Galvanic Isolation: Effectively prevent electromagnetic interference and protect the system from voltage spikes.
• Plug - and - Play Installation: Seamless integration with Mark VIe backplane, easy to replace and expand.
MRP680538
• Wide Input Voltage Range: Adapt to unstable industrial power grids and ensure stable power output.
• Multi - Level Protection: Overvoltage, overcurrent, short - circuit and overheating protection to prevent module damage.
• High Efficiency: ≥90% full - load efficiency, reducing energy consumption and heat generation.
• Dedicated for Mark VIe: Perfectly matched with IS200/IS230 series modules to ensure system compatibility and reliability.
3. Typical Applications
• Power Generation: Gas Turbine/Steam Turbine Control System, Generator Set Monitoring, Boiler Feed Pump Protection.
• Oil & Gas: Pipeline Compressor (Gas Turbine Driven), Offshore Platform Turbine Power System, Refinery Process Turbine.
• Metallurgy: Blast Furnace Blower Turbine, Rolling Mill Auxiliary Turbine, Waste Heat Recovery Turbine.
• Chemical Industry: Reactor Agitator Turbine, Centrifugal Compressor Turbine, Process Gas Turbine.
• Marine: Ship Propulsion Turbine, Marine Power Generation Turbine, Auxiliary Turbine System.
4. Installation & Maintenance
Common Installation Steps
• Mounting: DIN Rail or Chassis Mounting in Mark VIe Cabinet; Ensure Ventilation Clearance ≥20mm
• Wiring: Use Shielded Twisted - Pair Cable for Analog Signals; Connect Relay Outputs to Emergency Shutdown Circuit (Torque: 1.2 N·m)
• Power Connection: Connect MRP680538 to 85-265VAC Power; Check Polarity and Voltage Stability Before Power - on
• Configuration: Use Proficy Machine Edition Software to Set I/O Parameters, Protection Thresholds and Communication Addresses
Maintenance Recommendations
• Regular Inspection: Check Module LED Indicators Monthly; Verify Signal Accuracy Quarterly with Calibrator
• Firmware Update: Update Module Firmware Annually via GE Official Website to Ensure Compatibility with the Latest System
• Redundancy Test: Simulate Single Module Failure Quarterly to Verify Redundancy Switching Function
• Environmental Control: Maintain Cabinet Temperature at 0°C - 40°C; Keep Relative Humidity at 5% - 85% (Non - Condensing)
Technical Document | GE Mark VIe | IS200TPROS1CBB IS230TSPRH1C MRP680538 | Turbine Control & Protection System
