5SHY35L4512 3BHE014105R0001 5SXE08-0166 IGCT Power Module-KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ABB 5SHY35L4512 3BHE014105R0001 5SXE08-0166 IGCT Power Module
High-Power Energy Conversion & Precise Control for Heavy-Duty Power Electronic Systems
1. Product Overview
The ABB 5SHY35L4512 (3BHE014105R0001, 5SXE08-0166) is a high-performance Integrated Gate-Commutated Thyristor (IGCT) power module, a core component for medium and high-power electronic systems. It integrates a high-voltage, high-current IGCT chip, gate driver, and protection circuits, designed for applications requiring efficient power conversion, such as wind turbine converters, industrial high-voltage drives, Static Var Generators (SVG), and Flexible AC Transmission Systems (FACTS). The module features low on-state voltage drop, fast switching speed, and robust short-circuit protection, ensuring reliable operation in harsh industrial environments, and enabling efficient energy conversion and stable system control, making it an ideal choice for heavy-duty power electronic applications.
2. Key Technical Specifications
• Brand & Model: ABB 5SHY35L4512 (Ordering No.: 3BHE014105R0001, 5SXE08-0166)
• Product Type: Integrated Gate-Commutated Thyristor (IGCT) Power Module
• Core Function: High-Power AC-DC/DC-AC Conversion, Voltage/Current Regulation, System Protection
• IGCT Type: Symmetric IGCT (Reverse Conducting Capability)
• Rated Voltage: 4500 V (Collector-Emitter Voltage, VCES)
• Rated Current: 3500 A (Collector Current, IC, at 125°C)
• On-State Voltage Drop: 2.2 V (Typical, at Rated Current & Temperature)
• Switching Frequency: Up to 1 kHz (Continuous Operation)
• Gate Driver: Integrated ABB 5SXE08-0166 Gate Driver (Isolated Power Supply, Overvoltage Protection)
• Protection Functions: Overcurrent, Overvoltage, Overtemperature, Gate Fault Protection
• Isolation Voltage: 6000 V (Between Power & Control Circuit)
• Thermal Resistance: 0.025 K/W (Junction to Heat Sink)
• Cooling Method: Liquid Cooling (Recommended for Rated Load Operation)
• Power Supply (Control): 24 V DC (±10% Tolerance)
• Operating Temperature: -40°C to +125°C (Junction), -25°C to +85°C (Module Case)
• Storage Temperature: -40°C to +125°C
• Dimensions (W×H×D): 240 × 180 × 80 mm (9.4 × 7.1 × 3.1 in)
• Weight: Approx. 5.2 kg (11.5 lbs)
• Certification: CE, UL, IEC 60747-10, RoHS
3. Core Features
• High Power Density: 4500 V/3500 A Rating for Compact High-Power System Design.
• Low Conduction Loss: 2.2 V Typical On-State Voltage for High Energy Conversion Efficiency.
• Fast Switching: Up to 1 kHz Frequency for Precise Power Regulation & Dynamic Response.
• Integrated Protection: Comprehensive Overcurrent/Overvoltage/Overtemperature/Gate Fault Safeguards.
• Plug-and-Play: Integrated 5SXE08-0166 Gate Driver for Simplified System Integration.
• Symmetric Design: Reverse Conducting Capability for Bidirectional Power Flow Applications.
• Robust Packaging: Hermetically Sealed Ceramic Substrate for High Reliability in Harsh Environments.
• Easy Maintenance: Modular Design for Quick Replacement & Reduced Downtime.
4. Typical Applications
• Wind Power: Wind Turbine Full-Scale Converters (2-8 MW, Medium-Voltage Grid Connection).
• Industrial Drives: High-Power Motor Drives (Mining, Metallurgy, Cement Mill, Compressor).
• Power Grid: Static Var Generators (SVG), Unified Power Flow Controllers (UPFC), HVDC Transmission.
• Renewable Energy: Solar PV Inverter (Utility-Scale), Battery Energy Storage System (BESS) Converters.
• Railway: Traction Converters for High-Speed Trains & Electric Locomotives.
• Marine: Shipboard Power Converters, Propulsion Systems for Large Vessels.
5. Installation & Maintenance
• Mounting: Bolt to Forced Liquid Cooling Heat Sink (Torque: 25 N·m for M10 Bolts).
• Wiring: Connect AC Power Bus, DC Link, Gate Driver Signals, and Protection Circuits.
• Gate Driver Setup: Connect 24 V DC Power, Configure Protection Thresholds via Driver Interface.
• Cooling: Maintain Liquid Flow Rate ≥ 10 L/min, Inlet Temperature ≤ 40°C for Rated Load.
• Diagnostics: LED Indicators for Power, Gate Status, Fault Alarms; Support Remote Monitoring.
• Maintenance: Regularly Check Heat Sink Cleanliness & Cooling System; Inspect Power Terminals for Loosening.
