HIMA F3236 16‑Channel Safety Digital Input Module--KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
HIMA F3236 16‑Channel Safety Digital Input Module
Safety‑Related Digital Input Module for SIL3 Safety Instrumented Systems (SIS) - Critical Signal Acquisition & Processing
1. Product Overview
The HIMA F3236 is a 16‑channel safety‑related digital input module, a core component of HIMA's Safety Instrumented System (SIS) and PES (Programmable Electronic System) series. It is designed to collect and process critical safety signals (e.g., emergency stop, safety interlock, and alarm signals) in high‑risk industrial applications, such as chemical, oil & gas, and power generation. The module features a dual‑microprocessor architecture, full self‑diagnostic capabilities, and TÜV AK6/SIL3 certification (compliant with IEC 61508 and IEC 61511 standards), ensuring reliable operation in safety‑critical scenarios with a fault coverage rate exceeding 99%.
2. Key Technical Specifications
• Product Type: 16‑Channel Safety Digital Input Module (Safety‑Related)
• Brand & Model: HIMA F3236 (Compatible with HIMA PES/SIS Systems)
• Input Channels: 16 Independent Digital Input Channels
• Input Signal: 6 mA Current Signal (Including Cable Plug) or 24 V DC Mechanical Contact Signal
• Safety Isolation: Class AK 1‑6 (Compliant with TÜV Safety Requirements)
• Response Time: Typical 8 ms (Fast Signal Acquisition & Processing)
• Power Supply: 5 V DC (120 mA), 24 V DC (200 mA) (Dual Power Support)
• Operating Temperature: -20°C to +60°C (-4°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Humidity: 5%‑95% RH (Non‑Condensing)
• Protection Class: IP20 (Indoor Cabinet Mount)
• Space Requirement: 4 TE (DIN Rail Mount)
• Weight: 0.15 kg (0.33 lbs)
• Communication Protocol: PROFIBUS DP, Modbus TCP (Seamless Integration with DCS/PLC)
• Safety Certification: TÜV AK6/SIL3, IEC 61508, IEC 61511
3. Core Features
• SIL3 Safety Compliance: TÜV AK6/SIL3 certified, meeting the highest safety standards for critical applications.
• Dual‑Microprocessor Architecture: Two clock‑synchronized 32‑bit microprocessors (Intel 386EX, 25 MHz) ensure data consistency and fault tolerance.
• Full Self‑Diagnostics: Real‑time detection of input crosstalk, filter capacitor faults, and module malfunctions for proactive maintenance.
• Redundant & Isolated Design: Channel‑to‑channel and power isolation prevent signal interference and surge damage.
• Hot‑Swappable: Replaceable without system shutdown (in redundant configurations) for reduced downtime.
• Flexible Integration: Compatible with PROFIBUS DP, Modbus TCP, and HIMA PES/SIS systems for seamless data exchange.
• Diagnostic Logging: Automatically records 500 diagnostic logs for channel‑level fault location.
4. Typical Applications
• Oil & Gas: Emergency shutdown (ESD) systems, wellhead safety monitoring, and pipeline leak detection.
• Chemical Industry: Reactor safety interlock, pressure/temperature alarm signal acquisition, and hazardous material handling.
• Power Generation: Boiler safety protection, turbine overspeed protection, and flue gas emission monitoring.
• Pharmaceutical: Production line safety interlock and cleanroom access control.
• Water & Wastewater: Sewage treatment plant safety monitoring and chemical dosing system interlock.
5. Installation & Maintenance
• Mounting: 4 TE DIN rail mounting in control cabinets; Ensure proper alignment with HIMA PES backplane.
• Wiring: Use shielded cables for input signals; Channel‑to‑channel isolation prevents cross‑interference.
• Configuration: Use HIMA HIMatrix Engineering Studio to set input type, response time, and alarm parameters.
• Calibration: Factory‑calibrated; Self‑calibration via built‑in diagnostic functions (no manual adjustment needed).
• Maintenance: Regularly check power supply and communication connections; Use diagnostic logs for predictive maintenance.
• Troubleshooting: LED status indicators and HIMatrix diagnostic reports enable quick fault identification.
Technical Document | HIMA F3236 | 16‑Channel Safety Digital Input Module | SIL3 Safety Certification
