GE Multilin UR6DH Universal Relay & Protection Controller with Enhanced Communication for Power Systems
Product Description
The GE Multilin UR6DH is an advanced universal relay and protection controller within GE’s UR Series, optimized for medium/high-voltage power system applications requiring enhanced communication capabilities—including utility substations, industrial power networks, renewable energy plants, and critical infrastructure (data centers, hospitals). Building on the UR6CH platform, the UR6DH features expanded communication interfaces (dual Ethernet, fiber optic ports), enhanced cybersecurity protocols, and support for IEC 61850-9-2LE sampled values, while retaining comprehensive protection logic (overcurrent, voltage, frequency, earth fault) and 0.2% class precision metering. Engineered for high-availability systems, it offers redundant communication paths, dual power inputs, and compliance with IEEE C37.90/IEC 61850 standards, ensuring reliable fault detection, real-time monitoring, and secure integration with modern SCADA/EMS systems.
Key Functions
The UR6DH universal relay delivers enhanced protection, metering, and secure communication for power distribution systems. Key functions include: Full suite of protection logic (overcurrent/instantaneous overcurrent, under/over voltage, frequency protection 45-65 Hz, phase imbalance, earth fault, negative sequence protection); 0.2% class precision metering (V, I, kW, kVAR, kWh, power factor, THD) with 256 samples/cycle sampling rate; enhanced communication (dual 10/100/1000 Mbps Ethernet ports, fiber optic ports, IEC 61850 GOOSE/MMS/sampled values, Modbus TCP/RTU, DNP3.0); built-in cybersecurity (role-based access control, TLS 1.3, secure boot) for compliance with NERC CIP standards; 12 configurable digital inputs (24 VDC) and 10 Form C relay outputs (5 A @ 250 VAC/30 VDC) for advanced interlocking; event recording (2000 time-stamped events) and fault waveform capture (20 cycles pre/post fault) for detailed post-fault analysis; dual redundant power inputs (85-265 VAC/100-300 VDC) for high availability; and galvanic isolation (2500 VAC) between input/output circuits and control logic.
Application Scenarios
The GE Multilin UR6DH universal relay is deployed in mission-critical power systems requiring enhanced communication and cybersecurity. In utility transmission/distribution substations, it provides protection for transformers, feeders, and capacitor banks with secure, high-speed data transmission to SCADA/EMS via IEC 61850 sampled values. For large industrial plants (steel, chemical, oil & gas), it protects medium-voltage switchgear, motor control centers, and backup generator systems, with redundant communication paths to prevent data loss. In renewable energy installations (utility-scale solar/wind farms), it integrates with grid-tie inverters and battery storage systems to monitor grid parameters, provide anti-islanding protection, and comply with grid code requirements. The relay is also ideal for critical infrastructure (data centers, hospitals, railway electrification) where secure, uninterrupted power system monitoring and protection are essential for operational continuity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | Universal Protection Relay & Controller (Enhanced Communication UR Series) |
| Manufacturer | GE Multilin (GE Grid Solutions) |
| Model/Part Number | UR6DH |
| Protection Functions | Overcurrent (Definite/Inverse Time), Instantaneous Overcurrent, Under/Over Voltage, Frequency Protection, Phase Imbalance, Earth Fault, Negative Sequence Protection, Over/Under Power |
| Metering Accuracy | 0.2% Class (Voltage/Current); 0.5% Class (Power/Energy); Sampling Rate 256 Samples/Cycle |
| I/O Configuration | 12 Digital Inputs (24 VDC); 10 Form C Relay Outputs (5 A @ 250 VAC / 30 VDC); 4 Analog Inputs (0-5 A, 0-120 VAC); 2 Analog Outputs (4-20 mA) |
| Communication | Dual 10/100/1000 Mbps Ethernet (IEC 61850 GOOSE/MMS/Sampled Values, Modbus TCP); RS-485 (Modbus RTU, DNP3.0); 2x Fiber Optic Ports (Single-Mode/Multi-Mode); TLS 1.3 Cybersecurity |
| Isolation | Galvanic Isolation (2500 VAC) - Input/Output Circuits to Control Logic; Channel-to-Channel Isolation 1500 VAC |
| Power Supply | 85-265 VAC / 100-300 VDC (Dual Redundant Input); Max Power Consumption 25 W |
| Event Recording | 2000 Time-Stamped Event Logs; Fault Waveform Capture (20 Cycles Pre/Post Fault); Data Logging (1 Hz - 100 Hz Sampling Rate) |
| Operating Environment | Temperature: -40°C to +70°C (-40°F to +158°F); Humidity: 5-95% RH (Non-Condensing); Vibration: 5-2000 Hz, 5 g RMS |
| Certifications & Standards | IEEE C37.90, IEC 61850, IEC 60255, NERC CIP, CE, UL, CSA, ATEX, IECEx Approved |
| Mechanical Features | Panel-Mountable (19" Rack / DIN Rail); Front-Panel HMI (Color LCD + Keypad); LED Status Indicators; Dimensions: 178 x 178 x 254 mm (WxHxD) |
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
