TRICONEX 9563-810 24VDC Digital Input Termination Panel for Tricon SIL 3 Safety Instrumented Systems

Product Description

The TRICONEX 9563-810 is a dedicated 24VDC digital input termination panel (FTP/FTA) engineered by TRICONEX (Schneider Electric, former Invensys) for Tricon/Tricon CX SIL 3 safety instrumented systems (SIS). As a critical interface between field wiring and Triconex digital input modules (e.g., 3511, 3601E, 3604E), this panel provides a secure, isolated termination point for 24VDC digital input signals—with channel-level LED status indicators, surge protection, common-mode noise rejection, and screw terminal connections for easy field wiring & maintenance. It is designed to work with Triconex TMR I/O modules and remote expansion racks (e.g., 8112, 8101) in distributed emergency shutdown (ESD), fire & gas (F&G), and process safety applications—ideal for oil & gas, chemical, petrochemical, and power generation industries where harsh industrial environments demand robust signal termination and isolation.

Key Functions

The 9563-810 termination panel delivers reliable signal termination, isolation, and diagnostics for Triconex SIS 24VDC digital input channels. Key functions include: Dedicated termination for 16 isolated digital input points (24VDC, 18–30VDC operating range); channel-level LED indicators for signal status and fault diagnostics; built-in surge protection and common-mode noise rejection to safeguard I/O modules from field-side transients; screw terminal connections with wire guides for easy wiring and maintenance; compatibility with Triconex TMR I/O modules and remote expansion racks; compliance with IEC 61508 SIL 3, FM, CSA, ATEX, IECEx standards—ensuring reliable operation in harsh industrial environments.

Application Scenarios

The TRICONEX 9563-810 termination panel is deployed in safety-critical industrial applications requiring robust, isolated 24VDC digital input signal termination for Triconex SIS. In offshore oil & gas platforms, it terminates signals from wellhead ESD valves, subsea sensors, and fire protection devices—connected to remote I/O racks via fiber optics. For chemical and petrochemical plants, it supports signal termination for toxic gas detectors, emergency stop buttons, and safety valve actuators in distributed process units. In power generation facilities, it is used for turbine hall, boiler house, and switchyard digital input termination—enabling real-time monitoring and control of critical safety equipment. The panel is also suitable for mining, pharmaceutical, and water/wastewater treatment—all scenarios where field signal termination, isolation, and diagnostics are mandatory for SIL 3 compliance.

Technical Specifications

• Global Inventory Network: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses—supporting faster delivery and reduced logistics costs.
• Pricing & After-sales: Competitive prices paired with reliable after-sales warranty services.
• Customer Coverage: Serving clients across regions including the United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
• Product Quality Assurance: All products are brand new and original. Spare parts include a 1-year warranty, and all items undergo pre-delivery testing and certification.
• Discount Policy:
• Multi-product orders qualify for custom discounts (contact us for details).
• We offer further price adjustments if you receive a lower quote for identical products from other suppliers, tailored to your budget.
