TRICONEX 4609 Advanced Communication Module (ACM) for Tricon-Foxboro I/A Series Integration

Product Description

The TRICONEX 4609 is a high-integrity Advanced Communication Module (ACM), engineered by TRICONEX (Schneider Electric) to serve as a safety node interface between Tricon controllers and Foxboro I/A Series systems on the I/A Nodebus. This rack-mount, hot-spare compatible module enables secure, high-speed data exchange—transmitting Tricon aliased process data, diagnostics, and alarms to I/A Series workstations while supporting write protection, time synchronization, and uninterrupted communication via redundant/hot-spare configurations. It is purpose-built for SIL 3 safety instrumented systems (SIS) in critical industries, ensuring reliable integration between Tricon safety logic solvers and Foxboro I/A Series process control environments.

Key Functions

The 4609 ACM delivers safety-certified, high-performance communication between Tricon controllers and Foxboro I/A Series systems. Key functions include: acting as an I/A Series Nodebus safety node; full-rate transmission of Tricon aliased data (process variables, system aliases) and diagnostics; propagation of Tricon alarms to I/A Series destinations (consoles, printers) as system messages; Object Management Database (OMDB) integration for critical I/O point handling; time synchronization from the I/A Series environment; write protection to block unauthorized Tricon controller changes from I/A Series sources; hot-spare capability for continuous Nodebus communication; and LED status indicators for module health, port activity, and redundancy status.

Application Scenarios

The TRICONEX 4609 ACM is deployed in safety-critical industrial applications requiring seamless integration between Tricon SIS and Foxboro I/A Series process control systems. In offshore oil & gas platforms and refineries, it links Tricon emergency shutdown (ESD) and fire & gas (F&G) systems to Foxboro I/A Series operator workstations, enabling real-time safety data visualization and alarm management. For chemical and petrochemical plants, it integrates Tricon reactor safety interlocks with Foxboro batch control systems, ensuring coordinated safety actions and compliance with IEC 61508/61511 standards. In power generation facilities, it connects Tricon turbine/generator protection systems to Foxboro I/A Series plant monitoring networks, supporting regulatory compliance and operational reliability. The module is also used in mining, pharmaceutical, and water/wastewater treatment—all scenarios where secure, high-availability communication between safety and process control systems is mandatory.

Technical Specifications

• Global Inventory Network: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses—supporting faster delivery and reduced logistics costs.
• Pricing & After-sales: Competitive prices paired with reliable after-sales warranty services.
• Customer Coverage: Serving clients across regions including the United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
• Product Quality Assurance: All products are brand new and original. Spare parts include a 1-year warranty, and all items undergo pre-delivery testing and certification.
• Discount Policy:
• Multi-product orders qualify for custom discounts (contact us for details).
• We offer further price adjustments if you receive a lower quote for identical products from other suppliers, tailored to your budget.
