ABB MSR04XI Serial communication module

Time：2025-05-29 10:55:12 View count：

Product Number:ABB MSR04XI Serial communication module

Product Overview

ABB MSR04XI is a serial communication module. The following is its relevant information:

Functional features:

Serial communication function: It provides a serial interface for the system, conforming to the RS232-C standard, and can achieve serial communication connections between SC300E and with various remote devices.

Multi-port design: The front panel has four identical ports (ports 0 to 3) for communication connections, and these connections are also replicated on the field connector (J2) at the rear. Ports 0 to 3 are all RS232 interfaces. The baud rate can be set to 9600 or 19200 baud, and ports 2 and 3 must be set to the same baud rate. The ports are isolated from each other, and the isolation voltage is 1kV.

Diagnostic function: It has a diagnostic function. The front panel indicator can display Tx/Rx activity, circuit online status and module health status, which is helpful for quickly locating and solving problems that occur during communication.

Hot repair function: Supports single-slot hot repair. There is a switch on the front panel that can request the module to be taken offline, facilitating maintenance and module replacement during system operation without affecting the normal operation of the entire system.

Technical parameters:

Communication protocol: Serial communication protocol based on RS232.

Processor: Intel family microcontroller is adopted.

Module power consumption: 3.5W.

Dimensions: 400 (9U) height x 397 length x 28 width (unit: millimeters).

Weight: 1.3kg.

Application fields: It is suitable for various industrial automation scenarios and can be used in conjunction with AC500 and AC31 series PLCS to expand their I/O functions. It is widely applied in automated production lines, assembly lines, logistics systems and other fields. In the ABB robot system, the control and communication of robots can be achieved

ABB MSR04XI Serial communication module

This article is originally written by KIMI Xiaoming. Please bring the link www.xbplcdcs.com when reprinting

Client Concern

Part Number : ABB MSR04XI Serial communication module

Manufacture : ABB

Condition : Brand New with 12 month warranty

Lead Time : in stock

Status: 100% original

Payment method: T/T. Currencies for receipt: US dollar, New Zealand dollar, Chinese yuan, euro, Hong Kong dollar, Australian dollar, British pound, Canadian dollar, ruble and other global currencies

Sales Manager: Li Ming

WeChat: 18059884790

WHATSAPP:+86 18059884790

Click to add 【WHATSAPP】 and start a new experience of instant communication

Email:plc66@qq.com

ABB MSR04XI Serial communication module Not what you want?

For more product information about Bently Nevada, please click on (YMGK)

Hot Module

The following are some related products of ABB MSR04XI serial communication modules:

AI815 Analog input module: It features 8 analog inputs with HART straight-through function. The nominal input range is 0 (4)-+20 milliamperes and 0 (1)-+5 volts. It can be used in conjunction with MSR04XI to input analog signals into the system, achieving monitoring and control of analog quantities.

AI820 Differential Analog Input Module It features 4 differential and bipolar current/voltage inputs, suitable for applications requiring high common-mode suppression ratings and/or bipolar voltage or current inputs. The input range is ±20 milliamperes, ±10 volts, ±5 volts, and can be used together with the MSR04XI in systems that need to handle differential analog signals.

AO810/AO810V2 Analog output module: It features 8 unipolar analog output channels, capable of converting digital signals into analog signals for output, which is used to control external devices. When used in conjunction with MSR04XI, it can achieve the output control function of the system.

S800 series I/O module Such as SD821, SD822, SD823, etc., these modules have open ventilation plastic casings. At least three light-emitting diodes (fault, operation and warning) are provided at the front end of all I/O modules to indicate the module status. There are single module and redundant module applications, which can be jointly applied with MSR04XI in industrial automation control systems. Realize various input and output functions.

The AC500 and AC31 series PLCS: MSR04XI can be used in conjunction with these two series of PLCS to expand their I/O functions, achieve more complex control logic and communication functions, and is widely applied in various industrial automation scenarios.
