Product Number:Woodward 8440-1706 D Load sharing synchronizer module

Product Overview

Woodward 8440-1706 is a high-performance load-sharing synchronizer module, mainly used in industrial generator systems. The following is its specific introduction:

Functional features:

Synchronization function: Based on microprocessor design, it can achieve automatic frequency, phase and voltage matching for single-phase or three-phase AC generators. It has a slip frequency synchronization function, allowing for the selection of phase matching or voltage matching methods. It can also perform synchronization checks and synchronization time monitoring.

Load distribution: Provide load distribution control for generators driven by diesel or gas engines. Through analog or discrete output bias signals, achieve precise load sharing and ensure uniform load distribution among generators.

Protection function: It has a generator protection function, which can provide all-round protection for the generator, such as overcurrent, overvoltage, undervoltage and other protections. It can also achieve soft unloading and power limiting through relay output.

Communication function: Supports multiple communication protocols, such as Ethernet, CAN, Modbus, etc., facilitating communication and integration with other devices, and enabling remote control, monitoring, and parameter adjustment.

Technical parameters:

Power supply: Typically, a 24VDC power input is adopted, and some models support a 12VDC power supply. The power supply range is relatively wide, generally ranging from 8 to 32VDC, with a maximum power consumption of 18W.

Input and output: It features multi-functional configuration and can adapt to both digital and analog signals. The analog input supports 4 to 20 mA/1 to 5 VDC. The analog output speed deviation is ±2.5 VDC, 0.5-4.5 VDC, 1-5 VDC and many other options are available. A 500 Hz PWM output can also be provided. The discrete input is 18 to 40 VDC, 10 mA, and the relay driver output is 18 to 40 VDC, 200 mA junction.

Working conditions: The working temperature range is -40 ℃ to 70℃, and the ambient humidity can reach 95% at 38℃.

Dimensions and weight: The dimensions are approximately 264×461×58 millimeters, and the weight is about 800 grams.

Woodward 8440-1706 D Load sharing synchronizer module
