Product Number:3500/22-01-01-02 | 138607-01+146031-01 Bently Nevada | Transient Data Interface

Product Overview

3500/22-01-01-02 | 138607-01+146031-01 Bently Nevada Transient Data Interface Module Analysis

I. Product Overview

Brand and Positioning

Produced by Bently Nevada, it is a key module of its 3500 series mechanical protection system.

Function: Transient Data Interface (TDI), used for real-time collection, storage and transmission of transient data (such as vibration, displacement, rotational speed, etc.) during the operation of the unit, supporting fault diagnosis and performance analysis.

Ii. Model Analysis

Main model: 3500/22-01-01-02

3500/22

It represents the transient data interface module and is the core component for data acquisition in the 3500 series.

Suffix parameter (-01-01-02) :

The specific configuration should refer to the official manual, which usually involves communication protocols, the number of channels, power supply methods, etc. (The suffixes defined by different manufacturers may vary. It is recommended to confirm in combination with the technical documents.)

2. Component Number: 138607-01 + 146031-01

138607-01

It may be the component number of the TDI module body, including the hardware main body, circuit board and other core components.

146031-01

It may be a supporting accessory (such as cables, terminal modules or software licenses), used to achieve the connection or data interaction between the module and external systems (such as upper computers, PLCS).

Iii. Core Functions and Features

Data acquisition capability

It supports high-speed synchronous collection of multi-channel transient data (such as vibration waveforms and dynamic process data), with a sampling rate up to several thousand Hz.

Compatible with multiple sensor signals (such as accelerometers, eddy current probes, tachometer sensors, etc.).

Storage and Transmission

It is equipped with an internal cache or memory that can temporarily store transient data until it is transferred to an external system (such as via Ethernet, serial port or dedicated bus).

Supports real-time data stream transmission and is convenient for integration with condition monitoring software such as System 1 of Bently Nevada.

System compatibility

As part of the 3500 series, it can be seamlessly integrated into the frame structure of this series and work in coordination with other modules (such as vibration monitoring modules and rotational speed modules).

Industrial-grade design

It has the ability to resist vibration and electromagnetic interference, and is suitable for harsh industrial environments such as power plants, compressor stations and steam turbines.

3500/22-01-01-02 | 138607-01+146031-01 Bently Nevada | Transient Data Interface

This article is originally written by KIMI Xiaoming. Please bring the link www.xbplcdcs.com when reprinting

Client Concern

Part Number : 3500/22-01-01-02 | 138607-01+146031-01 Bently Nevada | Transient Data Interface

Manufacture : Bently Nevada

Condition : Brand New with 12 month warranty

Lead Time : in stock

Status: 100% original

Payment method: T/T. Currencies for receipt: US dollar, New Zealand dollar, Chinese yuan, euro, Hong Kong dollar, Australian dollar, British pound, Canadian dollar, ruble and other global currencies

Sales Manager: Li Ming

WeChat: 18059884790

WHATSAPP:+86 18059884790

Click to add 【WHATSAPP】 and start a new experience of instant communication

Email:plc66@qq.com

3500/22-01-01-02 | 138607-01+146031-01 Bently Nevada | Transient Data Interface  Not what you want?

Hot Module

I. 3500/22 Series Models (Subdivided by configuration)

3500/22-01-01-01

Standard configuration, supports Ethernet communication, suitable for basic data collection scenarios.

3500/22-01-01-02

Enhanced configuration may include redundant communication interfaces or higher storage capacity (as in the model you mentioned).

3500/22-02-01-XX

Special configuration supporting Profibus or Modbus protocols for integration with third-party systems.

Ii. Other related modules of the 3500 series

Data collection category

3500/20: Basic data interface module with a relatively low sampling rate, suitable for monitoring low-speed equipment.

3500/25: High-speed data acquisition module (sampling rate up to 25kHz per channel), used for high-frequency vibration analysis.

3500/40M: Monitor module, expandable for monitoring functions such as vibration and displacement.

Auxiliary function category

3500/32: Key phase/rotational speed module, providing phase reference for rotating machinery.

3500/92: Power module, providing redundant power supply for the system.

3500/93: Framework interface module, communication between management modules.

Iii. Alternative Models (Third-party Compatible Solutions)

Emerson

CSI 6500: Portable vibration analyzer, supporting transient data acquisition, can replace 3500/22 for temporary monitoring.

Honeywell

SENZA TR9739: Vibration monitoring system, supporting high-speed data acquisition and waveform analysis.

Rockwell Automation

Allen-Bradley 843T: Rotating machinery monitoring module, which needs to be combined with dedicated software to realize the TDI function.

Iv. Key Component Numbers (Spare Parts and Accessories)

138607-XX

TDI module motherboard (such as 138607-01 is a standard configuration motherboard).

146031-XX

Communication cables or terminal modules (e.g., 146031-01 is an Ethernet interface cable).

133292-XX

Module front panel display component (for status indication).

V. Selection Suggestions

High-frequency dynamic monitoring: 3500/25 (higher sampling rate) is preferred.

In scenarios with limited budget: Third-party compatible solutions can be considered (protocol compatibility needs to be verified).

System expansion requirements: Ensure an adequate number of frame slots and pair them with 3500/93 interface modules
