AC 800M Communication interfaces 3BSE069449R1 (CI854BK01)
Time:2025-05-09 14:27:40   View count:

Product Number:AC 800M Communication interfaces  3BSE069449R1 (CI854BK01)


Product Overview


PROFIBUS DP is a high speed multipurpose bus protocol (up to 12Mbit/s) for interconnecting field devices, like remote I/O, drives, low voltage electrical equipment, and controllers. PROFIBUS DP can be connected to the AC 800M via the CI854B communication interface. The CI854B includes two PROFIBUS ports to realize line redundancy and it also supports PROFIBUS master redundancy.

Master redundancy is supported in PROFIBUS-DP communication by using two CI854B communication interface modules. The master redundancy can be combined with CPU redundancy and CEXbus redundancy (BC810). The modules are mounted on a DIN rail and interface directly with the S800 I/O system, and other I/O systems as well, including all PROFIBUS DP/DP-V1 and FOUNDATION Fieldbus proficient systems.

The PROFIBUS DP must be terminated at the two outermost nodes. This is usually done by using connectors with built-in termination. To guarantee a correct working termination the connector has to be plugged and power supplied.

Package including: a CI854BK01 Communication Interface and a TP854 Baseplate.

(Only compatible with System 800xA 6.0.3.2, Compact Control Builder 6.0.0-2 and onwards. Please see Product Update for more information.)

General info
Article number3BSE069449R1 (CI854BK01)
Communication protocolPROFIBUS DP-V1
Master or slaveMaster
Number of channels2
Transmission speed9.6 - 12 000 kbit/s
Line redundancyYes
Module redundancyYes
Hot SwapYes
Used together with HI ControllerYes





3BSE069449R1 (CI854BK01)




AC 800M Communication interfaces 3BSE069449R1 (CI854BK01)



Sales Manager: Li Ming

WeChat: 18059884790

WHATSAPP:+86 18059884790

Email:plc66@qq.com



Express delivery is provided

Product Number:AC 800M Communication interfaces  3BSE069449R1 (CI854BK01)

Status: 100% original

Warranty period: 12 months.

Payment method: T/T. RMB (CNY) is supported.





For more product videos, please click to view




AC 800M Communication interfaces  3BSE069449R1 (CI854BK01) Not what you want?



Name
Communication protocol
Line redundancy
Master or slave
Module redundancy
COMLI and MODBUS RTU
No
Master/Slave
No
PROFIBUS DP-V1
Yes
Master
Yes
ABB's MasterBus 300
Yes
Master
No
ABB's S100 I/O
No
Master
No
ABB's INSUM
No
Master
No
ABB's DriveBus
No
Master
No
ABB's Satt I/O
No
Master
No
MODBUS TCP
No
Master/Slave
Yes
IEC 61850
-
-
No
ABB's Advant Fieldbus 100
Yes
Slave
Yes
PROFINET IO
No
Master
Yes
EtherNet IP / DeviceNet
No
Master
Yes
OPC UA Client
No
Master
Yes
