MOOG J866-1002 FLOW CONTROL PROPORTIONAL VALVES
Time:2025-05-08 14:53:05   View count:

Product Number:MOOG J866-1002 FLOW CONTROL PROPORTIONAL VALVES


Product Overview


J866 Series flow control proportional valves are throttle

valves for 3- and preferably 4-way applications. They are a

high performance, two-stage design that covers the range

of rated flows from 10 to 80 L/min at 7.0 MPa valve drop.

The output stage is a closed center, four-way, sliding spool.

The pilot stage is a symmetrical double-nozzle and flapper,

driven by a double air gap, dry torque motor. The spool

position is proportional to the coil curent. The valve

design is simple and rugged for dependable, long life

operation. These valves are suitable for Press Machines

and other applications with high stability and high

repeatability.








    MOOG J866-1002 FLOW CONTROL PROPORTIONAL VALVES



    Sales Manager: Li Ming

    WeChat: 18059884790

    WHATSAPP:+86 18059884790

    Email:plc66@qq.com



    Express delivery is provided

    Product Number:MOOG J866-1002 FLOW CONTROL PROPORTIONAL VALVES

    Status: 100% original

    Warranty period: 12 months.

    Payment method: T/T. RMB (CNY) is supported.





    For more product videos, please click to view
