ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells
Time:2025-05-08 14:45:31   View count:

Product Number:ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells


Product Overview


The Millmate Roll Force load cells act as integral parts of the mill stand. The rock solid Pressductor® load cell design in combination with the intelligent, reliable communication functions are crucial keys to true roll force measurement.

Due to its low impedance and high output signal power the Millmate Roll Force load cells has an extremely low sensitivity to insulation defects and maintains its measuring accuracy down to a 10kΩ insulation level.
The load cell output signal is calibrated for full interchangeability between load cells of the same type and size. The various types and the wide load range cover practically all conceivable roll force measurement applications


ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells



Circular load cells
Measuring range 1.6 - 60 MN
TypePFVL 141C MRF Circular LC resource_small
Nominal load (MN)1.6, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 51.5, 60


    Rectangular load cells
    Measuring range 0.63 - 56 MN
    TypePFVL 141VMRF Rectangular LC resource_small
    Nominal load (MN)0.63, 0.80, 1.0, 1.25, 1.6, 2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 12.5, 14, 16, 18, 20, 22, 25, 28, 31, 35, 40, 45, 50, 56


    Annular load cells
    Measuring range 2 - 28 MN
    TypePFVL 141RMRF Annular LC resource_small
    Nominal load (MN)2.0, 2.5, 3.1, 4.0, 5.0, 6.3, 8.0, 10, 11.2, 12.5, 14, 16, 18, 20, 22.4, 25, 28


    Annular load cells
    Measuring range 0.1 – 2.5 MN
    TypeQGPR 104/102MRF Annular LC resource_small
    Nominal load (MN)0.10, 0.16, 0.25, 0.40, 0.63, 1.0, 1.25, 1.6, 2.0, 2.5


     PFVL
     QGPR
    Accuracy class (% of Fnom)± 0.5 ± 1.0
    Linearity deviation (% of Fnom)≤± 0.5 ≤± 1.0
    Hysteresis (% of Fnom)≤ 0.2 ≤ 0.2
    Repeatability error (% of Fnom)≤ ± 0.1 ≤ ± 0.05
    Compression (mm at Fnom)0.05 0.05
    Calibration error (% of Fnom)0.1 0.1
    Compensation for min. error+20 - +80°C +20 - +80°C
    Zero point drift≤ ± 0.01%/°C ≤ ± 0.005%/°C
    Sensitivity drift≤ ± 0.01%/°C ≤ ± 0.01%/°C
    Working temperature range-10 - +90°C -10 - +80°C
    Max. permitted short-term temp.+110°C +110°C
    Storage temperature range-40 - +90°C -40 - +90°C


    ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells



    Sales Manager: Li Ming

    WeChat: 18059884790

    WHATSAPP:+86 18059884790

    Email:plc66@qq.com



    Express delivery is provided

    Product Number:ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells

    Status: 100% original

    Warranty period: 12 months.

    Payment method: T/T. RMB (CNY) is supported.





    For more product videos, please click to view




    ABB PFVL141C/PFVL141V/PFVL141R Roll Force load cells  Not what you want?


    PFVL141C, PFVL141V and PFVL141R are the pressure-measuring component models of ABB Company. The following are some related models:

    PFVO142: Matching unit, used for connecting the pressure head cable, can be used in conjunction with PFVL141C, PFVL141V, PFVL141R and other pressure heads.

    PFVA401F: Control unit, including the excitation unit PFVI401 and the control unit PFXA401F, is often used together with the above-mentioned indenter and matching unit in related measurement and control systems.

    In addition, within ABB's pressure head product series, there are other types and functions of pressure measurement elements, such as PFEA111 (conventional control unit, capable of connecting two pressure heads), PFCL201C (vertical pressure measurement element of pillow block tensiometer), PFTL101A (horizontal pressure measurement element of pillow block tensiometer), etc. Together with PFVL141C, PFVL141V and PFVL141R, they form a rich product line to meet the measurement requirements in different industrial scenarios.
