Emerson Ovation 5X00419G03 Ethernet Link Controller Module

Product Description

The 5X00419G03 is an Ethernet Link Controller module for Emerson Ovation DCS system, the upgraded revision of 5X00419G01 / 5X00419G02. It acts as a high-speed communication gateway between Ovation controllers and external Ethernet devices, supporting real-time data exchange, protocol conversion and upper SCADA connection. It adopts 10/100Mbps Ethernet interface, provides hot-swap function and built-in diagnostic LED indicators, widely used as spare parts for power plant and chemical Ovation control cabinets.

Features

• 10/100Mbps auto-negotiation Ethernet interface, full-duplex communication
• Supports Modbus TCP, TCP/IP and Ovation proprietary bus protocols
• Hot-swap capable, no need to shut down the whole rack during replacement
• Onboard status LEDs for network link, fault and activity diagnosis
• Supports redundant network configuration to improve system reliability
• Standard Ovation rack slot installation, compatible with Ovation I/O backplane
• Industrial wide temperature design, stable for long-term continuous operation
• Used for data transmission between Ovation controllers and third-party systems

Application Scenarios

• Thermal power plant Ovation DCS communication gateway
• Petrochemical, water treatment and pulp & paper Ovation control system
• Interconnection between Ovation controller and SCADA / HMI system
• Third-party PLC, instrument and auxiliary equipment Ethernet data access
• Ovation cabinet maintenance, spare parts replacement and system upgrade

FAQ

Q: What is the difference between G01, G02 and G03?
A: They are different hardware revisions; 5X00419G03 is the later updated version with optimized firmware and circuit design.

Q: Can it be hot swapped?
A: Yes, it supports hot-swap in the powered Ovation rack.

Q: What is the main function of this module?
A: It is an Ethernet link controller for Ovation DCS to realize Ethernet communication and protocol conversion.

Q: What communication protocols are supported?
A: Modbus TCP and standard TCP/IP, matched with Ovation internal control bus.
