B&R 8LSA55.EB030D000-1 8LS Synchronous Servo Motor

Product Description

The B&R 8LSA55.EB030D000-1 is a high-performance 3-phase synchronous servo motor from the 8LS series, designed for ACOPOS servo drive systems. It features a nominal speed of 3000 rpm, EnDat multi-turn inductive absolute encoder, self-cooling construction, swivel angled connector and smooth shaft without holding brake. It delivers 11.6 Nm nominal torque and 3.644 kW rated power with IP65 protection. The suffix -1 indicates the special variant version, different from the standard -3 version. It is widely used for precision synchronized motion and positioning in industrial automation machinery.

Product Functions

• High-precision closed-loop position, speed and torque control for automation motion axes
• EnDat multi-turn absolute encoder, saving position data without homing after power restart
• Support electronic cam, electronic gearing, linear and circular interpolation for synchronous production
• Self-cooling design for stable continuous operation under cyclic and peak overload conditions
• Rotatable angled connector for flexible wiring and convenient cabinet installation
• Fully compatible with B&R ACOPOS drives and programmed via Automation Studio software

Application Scenarios

• High-speed packaging, labeling and cutting machinery
• Printing, converting and textile production lines
• Plastic extrusion, thermoforming and injection molding auxiliary equipment
• Automated assembly stations, gantry robots and material handling systems
• Retrofit and spare replacement for B&R 8LS motion control systems
