HMS01.1N-W0020-A-07-NNNN (R911295323) Bosch Rexroth IndraDrive M Single-Axis Inverter

Product Description
HMS01.1N-W0020-A-07-NNNN, material number R911295323, belongs to Rexroth IndraDrive M HMS01 modular single-axis servo inverter (XMS1 series). It is a DC-bus servo axis module powered by the HMV series common DC bus power supply unit, converting DC bus voltage to controlled 3-phase AC output to drive synchronous/asynchronous IndraDyn servo motors. Rated continuous output current 20A, it is designed for multi-axis modular machine automation systems, widely used for CNC, metalworking and packaging equipment spare maintenance.

Key Features

• Modular single-axis inverter, powered by shared HMV DC bus power supply, continuous output current 20A
• Supports multiple encoder feedback: EnDat, Hiperface, resolver, incremental encoder
• Built-in STO Safe Torque Off safety function, optional extended safety modules
• High dynamic speed, torque and position closed-loop control, 1.5x overload capability
• Communication interfaces: SERCOS III, Profinet, Profibus DP, EtherNet/IP via optional interface card
• Compact rack-mounted modular design, easy multi-axis combination in shared DC bus cabinet
• Commissioning and parameter setup by Rexroth IndraWorks engineering software
• Legacy IndraDrive M platform; original production discontinued, available as NOS surplus or refurbished spare parts

Application Scenarios

• CNC machining centers, lathes, grinding machines and multi-axis machine tools
• Packaging machinery, printing equipment and textile automation lines
• Metal forming, laser cutting, handling and palletizing automation
• Multi-axis production equipment with common DC bus drive architecture
• Legacy IndraDrive M system spare replacement and retrofit projects

FAQ

Q: Does HMS01.1N-W0020-A-07-NNNN contain its own power supply?
A: No. It is an axis inverter only; it must pair with HMV series common DC bus power supply module.

Q: What software configures R911295323?
A: IndraWorks software for parameter setting, fault diagnosis and firmware upgrade.

Q: What motors are compatible?
A: Rexroth MKD, MSK, MHD series IndraDyn synchronous and asynchronous servo motors.
