Emerson P154 Prover Module for FloBoss S600 Flow Computer
Product Brief Description
The Emerson P154 is a dedicated prover interface expansion board designed exclusively for the FloBoss S600 flow computer system. It serves as a high-precision I/O card to connect flow provers, supporting automated meter proving operations for custody transfer measurement in oil & gas industry. This rugged plug-in module provides digital and pulse signal interfaces for sphere detectors and prover control equipment.
Product Functions
- Interface with compact, uni-directional, bi-directional and master meter provers, supporting up to 4 sphere detector switches
- 32 digital inputs and 12 digital outputs for prover sequence control and switch signal acquisition
- 2 frequency/density inputs and 4 hardware-assisted pulse outputs for high resolution timing and dual chronometry measurement
- Works with optional P148 pulse mezzanine to expand pulse input channels
- Automates full proving sequence and records traceable proving data for custody transfer reports
- Built-in channel diagnostic detection for field wiring fault monitoring
Application Scenarios
- Oil & gas pipeline custody transfer flow meter proving
- Refinery and natural gas metering station automated prover control
- Liquid and gas flow measurement verification for fiscal metering
- Petrochemical plant flow meter periodic calibration
- On-site field proving stations for high accuracy flow measurement audit
Frequently Asked Questions
Q: Which system is the P154 compatible with?
A: It is an expansion board dedicated for Emerson FloBoss S600 flow computer platform.
Q: Does P154 have analog input channels?
A: No, this prover board has no analog functions; it only handles digital, pulse and frequency signals.
Q: Can P154 use P148 pulse mezzanine module?
A: Yes, the P148 pulse mezzanine can be mounted on P154 to add extra pulse input capacity without occupying extra slots.
Q: What prover types can it support?
A: It supports compact prover, unidirectional prover, bidirectional prover and master meter prover.
Q: Can I use megger tester to check wiring on P154 connectors?
A: No, megger instruments generate excessive high voltage and will cause permanent damage to the P154 board.
