Brief Product Description

Foxboro P0904HN LZS 1500-3FOX is a termination assembly (TA) for Foxboro I/A Series DCS system. It acts as the field wiring terminal baseplate, providing signal wiring terminals, overvoltage protection, signal filtering and surge suppression between FBM fieldbus module and field instruments. It adopts screw terminal wiring design, connects with FBM card via dedicated flat ribbon cable. This termination unit is widely matched with early I/A FBM modules for analog / discrete signal marshalling. Foxboro (Schneider) discontinued this legacy product, only surplus and fully refurbished tested units are available for existing I/A DCS maintenance and spare replacement.

Core Product Functions

• I/A Series DCS Termination Assembly (TA) field wiring baseplate
• Bridge field instrument cables and FBM I/O module through dedicated ribbon cable
• Built-in surge protection, noise filtering for 4-20mA analog and discrete contact signals
• Screw type terminal block, convenient for field wiring, inspection and maintenance
• Provide signal isolation and overvoltage protection for field side loop
• Metal mounting base, cabinet DIN rail or panel mount installation
• Used together with corresponding FBM fieldbus module as complete I/O channel
• Onboard test points for convenient on-site signal measurement and troubleshooting

Application Scenarios

• Legacy Foxboro I/A Series DCS control cabinet signal termination unit
• Thermal power plant boiler, turbine DCS I/O signal wiring cabinet
• Petrochemical, refinery continuous process measurement and control signal marshalling
• Oil & gas, pulp & paper plant DCS field instrument wiring terminal assembly
• Water treatment, cement industry I/A DCS old cabinet spare replacement
• Existing I/A series DCS maintenance, spare parts and system retrofit

FAQ (Frequently Asked Questions)

• Q: I/A channel signal abnormal after installing P0904HN LZS1500-3FOX?
  A: Check ribbon cable connection between TA and FBM module, terminal screw tightness, surge protector damage, field cable short/ground fault, shielding grounding.
• Q: Can P0904HN match all FBM modules?
  A: No, each TA has fixed matching FBM model; must confirm compatibility of signal type and channel quantity before replacement.
• Q: What is the difference between P0904HN and P0924HN?
  A: Both belong to I/A termination assemblies; P0904HN is older generation TA; P0924HN is updated termination baseplate for later FBM200 series modules.
• Q: Is P0904HN LZS1500-3FOX available for new DCS projects?
  A: End-of-life legacy I/A component, no new original production. Recommend Foxboro Evo I/O system migration. Only surplus/refurbished tested spares for existing I/A DCS systems.
• Q: Common failure modes?
  A: Surge suppression component burnout, terminal corrosion, ribbon cable connector pin oxidation, internal wiring open circuit caused by long time high temperature environment.
