B&R 2CP100.60-1 Central Processing Unit (CPU)
The B&R 2CP100.60-1 is a central processing unit (CPU) module from the B&R SYSTEM 2010 generation. It combines 128 KB + 256 KB SRAM with a comprehensive set of built-in communication interfaces — RS232, isolated RS232/TTY and isolated RS485/RS422 — making it a robust control core for modular industrial automation systems. Application memory is ordered separately, allowing the CPU to be scaled to match the requirements of each machine or process.
- SYSTEM 2010 central processing unit
- 128 KB + 256 KB SRAM on board
- 1 × RS232 interface
- 1 × electrically isolated RS232/TTY interface
- 1 × electrically isolated RS485/RS422 interface (network-capable)
- Supports EN 61131-2 EMC and secure I/O bus protocol
Key Features & Functions
Powerful Control Core
RISC-based processing executes communication tasks simultaneously with I/O handling, enabling fast, deterministic processing of control signals.
Multiple Communication Interfaces
RS232, isolated RS232/TTY and isolated RS485/RS422 interfaces cover programming, HMI communication and networked field connections from a single CPU.
Electrically Isolated Ports
Isolated serial interfaces improve signal integrity and protect the CPU from ground loops and electrical interference in industrial environments.
Scalable Application Memory
Application memory is ordered separately from a range of modules, letting you right-size memory for the application rather than over-specifying the CPU.
Modular System Design
Hardware modularity enables flexible combination of I/O and communication modules to suit each machine configuration.
Industrial Reliability
Compliant with EN 61131-2 EMC requirements and equipped with a secure I/O bus protocol for dependable long-term operation.
Technical Specifications
| Model / Order Number | 2CP100.60-1 |
|---|---|
| Brand | B&R (Bernecker & Rainer) |
| Platform / Series | SYSTEM 2010 |
| Module Type | Central Processing Unit (CPU) |
| Memory | 128 KB + 256 KB SRAM |
| Interface 1 | 1 × RS232 |
| Interface 2 | 1 × RS232/TTY, electrically isolated |
| Interface 3 | 1 × RS485/RS422, electrically isolated, network-capable |
| EMC Standard | EN 61131-2 |
| Application Memory | Ordered separately (see compatible 2ME91x.90-1 modules) |
Disclaimer: The data above is compiled from published B&R product catalogue information for this material number. Please confirm the exact technical data, hardware revision and compatibility against the official B&R datasheet for 2CP100.60-1 before ordering or commissioning.
Compatible Application Memory Modules
| Module | SRAM | FlashPROM | Operating System |
|---|---|---|---|
| 2ME910.90-1 | 64 KB | 256 KB | PCC operating system |
| 2ME913.90-1 | 512 KB | 1 MB | PCC operating system |
| 2ME915.90-1 | 2 MB | 2 MB | PCC operating system |
Note: Application memory is not included with the CPU and must be ordered separately.
Typical Application Scenarios
- Machine Control: central control unit for modular production machinery and special-purpose machines.
- PLC & Industrial Computer Functions: combines PLC logic and industrial PC capabilities within one automation system.
- HMI Communication: dedicated serial interfaces for connecting operator panels and display systems.
- Networked Field Devices: isolated RS485/RS422 links for network-capable remote I/O and field equipment.
- System Upgrades & Retrofits: replacing the CPU in existing SYSTEM 2010 installations.
Frequently Asked Questions
What is the B&R 2CP100.60-1?
It is a central processing unit (CPU) module for the B&R SYSTEM 2010 automation platform, providing the control core with 128 KB + 256 KB SRAM and multiple serial interfaces.
How much memory does the 2CP100.60-1 have?
The CPU provides 128 KB + 256 KB SRAM on board. Application memory is ordered separately from compatible 2ME91x.90-1 modules.
Which communication interfaces are available?
It offers one RS232 interface, one electrically isolated RS232/TTY interface, and one electrically isolated RS485/RS422 interface that is network-capable.
Is application memory included?
No. Application memory must be ordered separately. Compatible options include the 2ME910.90-1, 2ME913.90-1 and 2ME915.90-1 modules with the PCC operating system.
Which system series does it belong to?
It belongs to the B&R SYSTEM 2010 generation. Cross-compatibility with other B&R platforms should be verified against your specific system configuration.
Where can I find the official datasheet?
Official technical documentation is available from B&R Industrial Automation and authorized distributors. We recommend verifying all specifications there before purchase.
