1900/65A-01-01-01-00-00 Bently Nevada General Purpose Equipment Monitor

Product Description

1900/65A-01-01-01-00-00 is Bently Nevada 1900/65A general-purpose machinery condition monitor, DIN-rail mount variant with attached local display. It uses external 110–220V AC 50/60Hz power supply, without extra safety certifications and no built-in communication ports. The unit has 4 transducer input channels for vibration, displacement or speed signals and 4 RTD temperature channels, continuously monitoring rotating and reciprocating plant equipment. It provides configurable alarm and trip relay outputs for machinery protection, and 4-20mA analog outputs to transmit measurement data to DCS or recorder systems.

Product Features & Functions

• 4 configurable transducer inputs, compatible with proximity probes, accelerometers and velocity sensors
• 4 RTD temperature channels for bearing, stator and casing temperature monitoring
• 110–220V AC 50/60Hz power, requires external AC-DC power supply unit
• Integrated attached local display and keypad for on-site parameter setup and real-time reading
• DIN rail mounting design for installation inside standard industrial control cabinets
• 6 programmable SPDT relay outputs for alert and danger alarm/trip functions
• 4 isolated 4-20mA analog outputs for connecting to DCS, PLC or chart recorders
• Onboard 200-event history log to record alarms, trips and diagnostic events
• Sensor fault diagnostics to detect open circuit, short circuit and transducer failure
• Configurable signal filters, alarm thresholds and time delays via local keypad or PC software
• Front panel LED indicators for power, alarm and trip visual status check

Application Scenarios

• Vibration and temperature protection for pumps, fans, blowers and small compressors
• Auxiliary rotating equipment monitoring in power plants, water treatment and cement factories
• Petrochemical, refinery and pulp & paper plant balance-of-plant machinery protection
• Retrofit and spare replacement of Bently Nevada 1900 series standalone monitoring systems
• Industrial cabinet-mounted condition monitoring for non-hazardous factory environments

FAQ

Q: What does suffix 01-01-01-00-00 mean?
A: 01 = 110–220V AC power (external supply); 01 = attached local display; 01 = DIN rail mounting; 00 = no approvals; 00 = no communication interface.

Q: What is the difference from 1900/65A-00-01-01-00-00?
A: This model (-01 power) uses 110/220V AC with external PSU; 00 power variant accepts direct 18–36VDC input.

Q: Is 1900/65A series still in production?
A: The 1900/65A series is still active by Bently Nevada (Baker Hughes). Original new units are available via authorized distributors.
