1381-647980-12 TEL TVB-1202-1/ANET VME Communication Control Board

Product Description

1381-647980-12, also known as TVB-1202-1/ANET, is a VME bus industrial communication control board manufactured by TEL (Tokyo Electron). This VME plug-in board is designed for semiconductor manufacturing equipment. It integrates onboard processor, memory, Ethernet transceiver and BNC interface, responsible for high-speed network communication and equipment motion/process data exchange between host controller and peripheral units inside wafer processing tools.

Product Features & Functions

• Standard VME bus form factor for installation in semiconductor equipment VME rack
• On-board CPU and memory for local data processing and protocol handling
• Equipped with Ethernet port and BNC coaxial interface for dual communication options
• High-speed data transmission for wafer tool process parameters and status feedback
• LED indicators on front panel for power status, communication activity and fault diagnosis
• Industrial-grade PCB and components for stable continuous operation in cleanroom environment
• Real-time data exchange to coordinate subsystems of semiconductor processing machines

Application Scenarios

• TEL semiconductor wafer processing equipment control system
• VME rack based equipment host communication and data management
• Semiconductor fab equipment maintenance and spare parts replacement
• Wafer etching, deposition and cleaning tool subsystem interconnection
• Legacy TEL process equipment overhaul and control hardware retrofit

FAQ

Q: What is the alternate model name for 1381-647980-12?
A: The alternate model is TVB-1202-1/ANET, both refer to the same TEL VME communication control board.

Q: What bus standard does this board use?
A: It adopts VME bus standard, designed for VME rack used in TEL semiconductor production equipment.

Q: Is this TEL board still in original production?
A: This legacy VME board has been phased out by TEL. Only new old stock, used and refurbished boards are available in spare parts market.
