0010-70441 AMAT Applied Materials PVD HP Lift Assembly

Product Description

0010-70441 is a motorized lift assembly manufactured by Applied Materials, engineered for AMAT 5500 PVD mainframe systems. This precision mechanical unit mounts within the vacuum chamber, constructed from vacuum-compatible metal materials to withstand the low-pressure environment of sputter deposition. It serves as a core wafer handling component to achieve stable vertical movement for wafer loading, positioning and height tuning during thin film processing.

Product Features & Functions

• Provides accurate vertical motion control for wafer pick-up and placement inside the PVD vacuum chamber
• Adjusts wafer working height to ensure uniform metal sputtering deposition
• Vacuum compatible mechanical structure for continuous cyclic operation
• Designed to match the original motion interface of AMAT 5500 PVD platform
• Maintains stable mechanical performance under chamber process conditions

Application Scenarios

• Semiconductor wafer PVD sputtering production
• Wafer positioning and transfer inside vacuum process chamber
• Metal thin film deposition for integrated circuit manufacturing
• Maintenance and spare part replacement for AMAT 5500 PVD mainframe

FAQ

Q: Which equipment platform is 0010-70441 compatible with?
A: It is specially designed for AMAT 5500 PVD mainframe. It cannot be directly used on Centura or Endura platforms without modification.

Q: Can the used 0010-70441 assembly be refurbished?
A: Yes. Refurbishment includes mechanical overhaul, seal replacement and motion calibration after rebuild.

Q: Is there an OEM alternative part number for this lift assembly?
A: There is no direct OEM substitute. The standard maintenance solution is to replace the whole assembly once it fails.
