WOODWARD 9905-990 Digital Turbine Speed Governor Control Module

Product Description

The 9905-990 is a high-reliability industrial digital speed governing control module independently developed by Woodward, belonging to the classic 2301 series digital control product line. As the core precision speed regulation component specially designed for industrial rotating machinery control scenarios that have extremely strict requirements for speed control accuracy and continuous operation stability, it is widely deployed in heavy-duty industrial scenarios such as industrial diesel generator sets, small and medium-sized steam/gas turbines, mechanical drive compressors and other fields that have extremely high demands for operation safety, responsible for accurately executing high-precision speed closed-loop regulation, multi-unit load distribution and overspeed safety protection control logic, ensuring that the rotating equipment can continuously and stably operate without interruption during long-cycle uninterrupted production, providing the most fundamental high-reliability speed control guarantee for the operation safety of industrial rotating machinery.

Core Technical Specifications

• Manufacturer: Woodward, original industrial turbine speed control grade production standard
• Product Category: Industrial 2301 series digital speed governor control module, official part number 9905-990
• Physical Parameters: Compact industrial modular design, net weight about 2kg, IP20 protection grade, fully compliant with industrial anti-vibration and anti-electromagnetic interference standards for rotating machinery control scenarios
• Electrical Parameters: 24V DC wide voltage industrial power supply, maximum power consumption 15W, with built-in power supply overvoltage and reverse connection protection circuit
• Performance Parameters: Adopting 32-bit high-performance industrial processor, the control loop response time is less than 3ms, the speed control accuracy can reach within ±0.05% of the rated speed, which can efficiently execute complex PID speed regulation and load distribution algorithms
• Memory Configuration: 2MB user program RAM, 4MB non-volatile Flash memory, no need for backup lithium battery to realize long-term configuration data retention, effectively avoiding data loss caused by battery aging
• Communication Capability: Natively supports Modbus RTU, Modbus TCP industrial communication protocols, with 2 independent RS232 serial ports, which can seamlessly realize data interconnection with Woodward dedicated operation panel, on-site DCS/PLC system and upper monitoring platform
• Operating Environment: 0°C to +50°C industrial working temperature range, 5%-95% non-condensing relative humidity, mean time between failures (MTBF) as high as 1.5 million hours, certified by CE and DNV marine certification

Key Product Functions

• High-Precision Steady Speed Regulation Control: The module integrates Woodward's exclusive adaptive speed measurement and filtering algorithm, which can effectively eliminate the speed signal jitter interference caused by vibration, so that the speed fluctuation of the controlled rotating equipment is always stably controlled within a very small range, ensuring the stable operation of the generator set frequency or the constant speed working condition of the compressor unit.
• Multi-Generator Set Synchronous Load Distribution: The controller supports multi-generator set parallel operation control, which can automatically realize equal-proportion load distribution according to the capacity of each unit, and complete the grid synchronization operation within 1 second, effectively improving the operation efficiency of the whole power generation system.
• Full-Coverage Safety Protection Mechanism: The module has built-in multi-level safety interlock protection logic, which can quickly trigger the emergency trip protection action when the controlled equipment has abnormal states such as overspeed, oil pressure loss and vibration over-limit, and the protection action response time is less than 5ms, effectively avoiding major equipment damage accidents of the rotating unit.
• Perfect System Compatibility: The module is fully compatible with Woodward 2301 series speed governor systems, can seamlessly connect with the existing system fuel actuator, speed sensor and operation panel, no need to replace the existing system hardware in large quantities, which can be directly used as spare parts for the maintenance and replacement of old Woodward speed control systems that have been in operation for many years, effectively extending the service life of the old control system.
• Full Self-Diagnosis and Fault Locating: The module continuously performs real-time all-round health monitoring on the operation state, speed sensor signal state and communication link state, automatically identifies abnormal states such as sensor signal loss, communication interruption, module hardware fault, and uploads fault alarm information to the upper monitoring platform in time, helping maintenance personnel quickly locate system hidden dangers and effectively shorten the system fault recovery time.

Typical Application Scenarios

• Power generation industry: Small and medium-sized diesel/gas engine generator set control system, responsible for the core speed regulation and load distribution control of the unit.
• Petrochemical industry: Small and medium industrial steam turbine and centrifugal compressor unit control system, realizing stable and reliable speed regulation and working condition control of the compressor.
• Marine engineering industry: Marine main engine auxiliary speed control system, realizing high-reliability operation control of the generator set on the ship.
• Industrial drive industry: Large industrial pump set and fan speed regulation control system, realizing efficient energy-saving operation control of the equipment.
• Industrial transformation and upgrading projects: Spare parts replacement and system maintenance of old Woodward 2301 series speed control systems that have been in operation for many years in various industrial sites.
