GE 104X905BA603 (NP104X905BA603) Product Description

GE 104X905BA603 is the operator interface display & keypad panel for GE Mark VI turbine control systems. This front-panel HMI unit integrates an LCD screen and membrane keypad, enabling operators to view real-time turbine parameters, alarm logs, generator status, set points and execute local control commands. It communicates with the Mark VI core controller via serial link, serving as local human-machine terminal for gas/steam turbine control cabinets. It is widely stocked as fully-tested spare replacement hardware for legacy GE turbine control panel overhaul.

Product Features

• Integrated LCD display and industrial membrane keypad for turbine local operation
• Dedicated serial communication interface to connect with GE Mark VI turbine controller
• Displays real-time speed, temperature, vibration, pressure and system alarm information
• Supports local parameter modification, trip reset and alarm acknowledgement
• 24VDC power supply, low power consumption for continuous cabinet operation
• Front panel IP-rated protection against dust and minor splash inside control room
• Industrial wide operating temperature range, high vibration resistance for turbine cabinet
• Built-in self-diagnosis, reports communication failure and hardware fault on screen
• Standard panel cutout mounting, direct swap for original Mark VI cabinet front panel

Application Scenarios

• Power plant GE Mark VI gas turbine and steam turbine control cabinets
• Generator set local monitoring, alarm management and manual operation interface
• Oil & gas pipeline gas turbine driven compressor control panels
• Industrial power station and cogeneration turbine monitoring systems
• Marine gas turbine generator control and local operator station
• Retrofit, maintenance and spare replacement for legacy GE Mark VI turbine HMI panels
