Product Brief Description

The Allen-Bradley 80026-529-01-R is a 1000W single-phase AC/DC power supply unit designed exclusively for Rockwell PowerFlex 7000 medium voltage variable frequency drives. It supplies stable auxiliary power to the internal control circuits, gate drive boards and monitoring subsystems of the MV drive. This discontinued industrial power unit features rugged construction for heavy-duty power plant and mining environments, widely used as spare replacement part for existing PowerFlex7000 installations.

Product Features & Functions

• 1000W single-phase AC to DC conversion for medium voltage drive auxiliary power
• Built-in overvoltage, undervoltage, overload and short-circuit protection
• EMC filtering design to suppress high-frequency noise inside high-power drive cabinet
• Stable continuous output to support drive control and gate trigger electronics
• Robust metal enclosure, high vibration and temperature resistance for industrial cabinets
• Internal fault diagnostic with status indication for quick troubleshooting
• Direct replacement spare part for PowerFlex 7000 medium voltage AC drive system

Application Scenarios

• PowerFlex 7000 medium voltage variable frequency drive auxiliary power supply
• Mine large fan, pump and conveyor medium voltage motor drive systems
• Power station boiler feed pump and induced draft fan MV drive control cabinets
• Petrochemical, cement plant heavy-duty medium voltage motor speed regulation
• Industrial medium voltage drive maintenance, retrofit and spare part replacement
