• OVERVIEW The SSA Chassis managed switch provides 48 SFP and four (4) SFP+ 1000Base-X 1Gb uplink ports.

• The switch allows high-performance, full-featured Ethernet switching in small to medium-sized network applications,

• as well as high-performance direct endstation connectivity.

• Distributed switching architecture with redundant processors and integral load-sharing redundant power supplies help make the SSA Chassis managed switch reliable.

•  The features of the SSA Chassis managed switches (P0973LN) are:

•  Up to 48 - 1000Base-X 1 Gb SFP uplink ports or 100Base-X SFP device ports

•  4 SFP+ uplink ports configured as 1G ISL uplink ports

•  Configuration tasks through a local console port, and monitoring through any SNMP/RMON based management application

•  Distributed switching architecture for optimum uptime

•  When installed with the optional redundant power supply, there is no single point of failure due to power disruptions.

• Table 3 lists the MGBIC modules that can be added to the SSA chassis (SFP) Port Managed Switch (P0973LN) switch.

• The MGBIC modules are added to specific SFP ports to provide connectivity for ISL or device ports

POWER SUPPLY

• A 450 watt power supply P0973LQ can be ordered for the P0973LN (power supplies are ordered separately).

• Each power supply installed requires one separately fused, 15-amp power circuit within 182 cm (6 ft) of the power supply.

• For redundancy, an optional second supply slot is available.


Product Picture
