Product Description

GE IS200TRPGH1BDD S1C5029 Trip Solenoid Control Terminal Board

Mark VI Speedtronic Primary Trip Terminal Board for Gas Turbine Trip Solenoid Control, Flame Detection & Safety Interlock

1. Core Product Overview

The GE IS200TRPGH1BDD S1C5029 is a primary trip terminal board (TRPG) for Mark VI Speedtronic turbine control systems, dedicated to trip solenoid control, Geiger-Mueller flame detector monitoring, and safety interlock execution in gas/steam turbine applications. As a key safety component, it features relay-based trip logic, metal oxide varistor (MOV) surge protection, dual redundant 24V DC power inputs, and removable terminal strips for secure wiring. The board integrates with Mark VI controllers via backplane communication, supporting simplex/dual redundancy for fault-tolerant operation, and includes three D-shell connectors for cable interfaces and two terminal strips for field device connections. It is designed for -40°C to +70°C industrial environments, with conformal coating and IP20 protection for reliable performance in harsh power generation, oil & gas, and petrochemical settings.

• Core Role: Trip solenoid control; flame detector monitoring; safety interlock execution; surge protection; Mark VI backplane integration • Model Info: IS200TRPGH1BDD (full part number); S1C5029 (serial code); TRPG primary trip terminal board; Mark VI Speedtronic series • Key Specs: Dual 24V DC power; relay-based trip logic; MOV surge protection; 2 terminal strips; 3 D-shell connectors; -40°C~+70°C operating temp • Reliability: Simplex/dual redundancy; surge suppression; conformal coating; industrial EMC immunity; 24-month warranty

GE IS200TRPGH1BDD S1C5029-07.jpg

2. Circuitry & Safety Function

The IS200TRPGH1BDD S1C5029 employs relay-based circuitry for high-speed trip solenoid actuation, ensuring rapid response to safety critical conditions (e.g., overspeed, flameout, pressure anomalies). Metal oxide varistors (MOVs) provide surge suppression to protect against voltage spikes, while dual redundant power inputs prevent single-point power failures from disabling trip functions. The board monitors Geiger-Mueller flame detectors to confirm combustion presence, triggering trip logic if flames are absent, and integrates with Mark VI backplane for real-time status feedback and control commands. It features removable terminal strips for easy wiring maintenance and three D-shell connectors for secure cable connections, with LED indicators for power, trip status, and communication health. The design supports backward compatibility with earlier TRPG revisions, ensuring seamless system upgrades.

• Circuit Design: Relay-based trip logic; MOV surge protection; redundant power switching; isolated I/O circuits; flame detector signal processing • Safety Logic: Overspeed trip; flameout detection; pressure/temperature interlock; emergency shutdown (ESD) execution; fail-safe relay actuation • Connectors: 2 removable terminal strips (field wiring); 3 D-shell connectors (backplane/cable interfaces); secure locking mechanisms; anti-vibration design • Redundancy: Dual 24V DC power; simplex/dual controller communication; cross-wired trip logic; fault isolation between channels

GE IS200TRPGH1BDD S1C5029-02.jpg

3. Integration & Compliance

The IS200TRPGH1BDD S1C5029 integrates with Mark VI controllers via backplane communication, enabling real-time status monitoring and trip command execution. It supports ToolboxST software for configuration, fault diagnostics, and firmware updates, with LED indicators for quick visual inspection of power, communication, and trip status. The board complies with IEC 61010-1 electrical safety, IEC 61000-4 EMC immunity, and UL 61010 standards, with Class I, Div 2/ATEX Zone 2 hazardous area certification for use in explosive atmospheres. It is designed for panel mounting with standard industrial enclosures, featuring removable terminal strips for easy field wiring and maintenance, and dual power inputs with overvoltage/undervoltage protection to ensure reliable operation during power fluctuations.

• System Integration: Mark VI controller backplane; ToolboxST configuration; LED status monitoring; real-time trip command execution • Power Supply: Dual 24V DC inputs; overvoltage/undervoltage protection; power failure alarm; redundant power switching • Compliance: CE/UL 61010/IEC 61000-4; Class I, Div 2/ATEX Zone 2; industrial EMC immunity; RoHS compliant • Environmental: -40°C~+70°C operating temp; 5–95% non-condensing humidity; IP20 protection; conformal coating

GE IS200TRPGH1BDD S1C5029-01.jpg

4. Installation & Maintenance

Installation Notes: Panel mount; dual 24V DC power connection; terminal strip wiring (field devices); D-shell connector for backplane; ToolboxST initial setup.

Configuration: Trip logic setup; flame detector threshold calibration; redundancy configuration; LED status verification; communication parameter setting.

Maintenance: Visual inspection (burn marks, loose connections); terminal strip cleaning; surge protection (MOV) check; 6-month preventive maintenance.

Quality & Warranty: GE genuine module; factory-tested for Mark VI compatibility; 24-month standard warranty; technical support for trip logic configuration and system integration.
