Yaskawa CP-9200SH-SVA 4-Axis Analog Servo Control Module

Precision Analog Servo Control for CP-9200SH Machine Controller Series

1. Core Overview

The Yaskawa CP-9200SH-SVA is a 4-axis analog servo control module for the CP-9200SH integrated machine controller, combining sequence (PLC) and motion control for high-speed, multi-axis industrial automation. It delivers independent position, speed, torque, and differential control per axis, with a single CPU supporting up to 11 SVA modules (total 44 axes) for flexible system scaling. Designed for precision manufacturing (semiconductor, packaging, machine tools), it integrates via CP-9200SH backplane, with hot-swappable design, 24Vdc backplane power, and galvanic isolation for reliable operation in harsh industrial environments.

• Core Role: 4-axis analog servo control; position/speed/torque/differential modes; sequence + motion integration • Model Info: CP-9200SH-SVA (SVA module); Yaskawa CP-9200SH series; JACP-921900 (spare PN: 87921-90001-S0102) • Key Specs: 4 axes/module; 24Vdc backplane; -10°C to +50°C; 3.2W power; 2.5kV isolation • Scalability: Up to 11 SVA modules per CPU; 44 axes total; modular expansion for production flexibility

CP-9200SH-SVA (3).jpg

2. Control Performance & I/O Interface

Each SVA module provides 4 independent analog servo channels (±10V speed/torque; 16-bit resolution) for Yaskawa servo drivers, with 100µs loop update and 50kHz output frequency for ultra-precise motion. It includes digital I/O (8 in/8 out) for home/limit switches, 2 encoder feedback ports (A/B/Z, 1MHz), and 2.5kV galvanic isolation between channels/backplane to suppress noise. Front-panel LEDs indicate module power, axis activity, and faults, while CP-717 programming software enables parameter tuning, motion logic setup, and real-time diagnostics.

• Control Modes: Position (±10V command), speed (±10V), torque (±10V), differential (electronic gear) • Analog Output: 4 channels (±10V, 16-bit); 100µs update; 50kHz output frequency • Feedback: 2 encoder ports (A/B/Z, 1MHz); incremental/absolute encoder compatibility • I/O: 8 digital inputs (24Vdc); 8 digital outputs (24Vdc, 0.5A); 4-20mA for DCS/PLC integration

CP-9200SH-SVA (5).jpg

3. CP-9200SH System Integration

The SVA module mounts in CP-9200SH racks (short/long bases; max 4 bases) and connects via backplane to CPU modules (1-2 CPUs, independent program execution). It supports up to 16 motion modules (SVA + PO-01) per system, with shared memory for 100ns inter-module data exchange, enabling high-speed synchronous motion (e.g., electronic gearing, cam profiling). Hot-swappable design allows replacement without system shutdown, and CP-717 software provides "One-Shot" configuration, I/O mapping, and remote troubleshooting via Modbus RTU/TCP.

• Rack Compatibility: CP-9200SH power/CPU modules; short/long mounting bases; up to 4 bases linked • Communication: Backplane (100ns data exchange); Modbus RTU/TCP; CP-717 programming interface • Installation: Hot-swappable; backplane-powered (24Vdc); DIN-rail compatible; 5.1×25.4×11.4cm (0.5kg) • Redundancy: Dual CPU support; module-level redundancy for critical motion axes

CP-9200SH-SVA (1).jpg

Typical Applications & Compliance

Key Sectors: Semiconductor manufacturing, packaging machinery, machine tools, automotive assembly, printing.

Use Cases: Multi-axis synchronous motion, electronic gearing, cam profiling, precision positioning, torque control for material handling.

Compliance: CE, UL 508, IEC 61010, RoHS; EMC (IEC 61000); -10°C to +50°C operating temperature.

Spare Part Grade: Yaskawa original; factory-tested for CP-9200SH compatibility; 1-year standard warranty.
