ICS TRIPLEX（三重冗余）
ICS TRIPLEX T8111C / T8111 TRUSTED TMR PROCESSOR MODULE-KIMI
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
ICS TRIPLEX T8111C / T8111 TRUSTED TMR PROCESSOR MODULE
3-2-0 Triple Modular Redundant Fault-Tolerant Processor for SIL 3 Safety-Critical Systems
1. Product Overview
The ICS TRIPLEX T8111C / T8111 is the core Trusted TMR processor module of Rockwell Automation's Trusted safety system, adopting a 3-2-0 triple modular redundant architecture with hardware voting to ensure continuous operation even when a single processor fails. It integrates HIFT (Hardware Implemented Fault Tolerance) technology, automatic fault handling, and time-stamped fault logging, supporting IEC 61131-3 programming languages for flexible application development. The T8111C is the conformal-coated version of the T8111, providing enhanced corrosion resistance for harsh industrial environments with sulfur-containing gases or high humidity, both designed for critical applications like emergency shutdown (ESD), fire and gas monitoring, turbine control, and process safety instrumented systems (SIS) requiring SIL 3 integrity.
2. Key Specifications
• Module Type: Trusted TMR Processor Module (3-2-0 Redundancy, Hardware Voting)
• Model Difference: T8111C (Conformal Coated); T8111 (Standard, Non-Coated)
• Processor Architecture: 32-bit True-Multiplication™ TMR Core, Lock-Step Parallel Operation
• Memory: 32 MB RAM, 128 MB Flash Memory (Expandable via Optional Modules)
• Power Input: 24 V DC (20 V - 32 V DC Compatible), Max Power Consumption: 5 W
• Communication Interfaces: Ethernet (TCP/IP), RS-232, RS-485 (Modbus RTU/TCP), Inter-Module Bus (IMB)
• Programming Support: IEC 61131-3 (LD, FBD, ST, IL, SFC)
• Operating Temperature: -40°C to +70°C; Storage Temperature: -40°C to +85°C
• Mechanical: Rack-Mount, Hot-Swappable; Dimensions: 180mm×130mm×40mm; Weight: 0.9 kg (T8111), 1.0 kg (T8111C)
• Safety Certifications: IEC 61508 SIL 3, ATEX, IECEx, CE, UL Listed
• Environmental Protection: T8111C: Conformal Coating (H₂S/SO₂ Resistant, IEC 721-3-3 Class 3C2); T8111: Standard Protection
YMGK Purchase Information
This section covers key details customers care about regarding purchasing, to support your global industrial product procurement needs.
One-Stop Global Industrial Product Procurement
- Global Inventory: 121 shared inventories worldwide, enabling direct procurement from overseas warehouses for faster delivery.
- Pricing & After-Sales: Competitive prices plus reliable after-sales warranty services.
- Customer Coverage: Serving clients across United States, Germany, Japan, South Korea, United Kingdom, France, Italy, Canada, Brazil, India, Australia, Russia, Spain, Netherlands, Switzerland, Sweden, Belgium, Austria, and Turkey.
- Product Quality: All items are brand new and original. Spare parts include a 1-year warranty, and all products are tested and certified.
- Discounts: Contact us for bulk-order discounts. We also offer further price adjustments if you receive lower quotes for identical products from other suppliers.
For additional inquiries, reach out to us at any time.
All product names, trademarks, brands, and logos on this site belong to their respective owners. Their use here is for identification only, and does not imply affiliation with or authorization from the rights holders
3. Core Features & Benefits
• 3-2-0 TMR Architecture: Three parallel processors with hardware voting, eliminating single-point failures for 100% system availability
• HIFT Technology: Hardware-implemented fault tolerance for rapid fault detection, isolation, and recovery without software intervention
• Conformal Coating (T8111C): Enhanced durability in corrosive environments, extending service life in oil & gas and chemical plants
• Seamless I/O Integration: Inter-Module Bus (IMB) for connecting Trusted I/O modules (e.g., T8401, T8402, T8403) with auto-detection
• Real-Time Diagnostics: Time-stamped fault logging, module health monitoring, and remote diagnostic access via Ethernet
• Hot-Swappable Design: Module replacement without system shutdown, minimizing maintenance downtime
• SIL 3 Compliance: Meets the highest safety integrity level for critical SIS applications, ensuring regulatory compliance
4. Typical Applications
• Oil & Gas: Emergency Shutdown (ESD), Fire & Gas Detection, Pipeline Monitoring, Offshore Platform Safety Systems
• Petrochemical: Reactor Safety Control, Burner Management, Toxic Gas Monitoring, Pressure Relief Valve Actuation
• Power Generation: Turbine Protection, Boiler Safety Interlocks, Switchgear Control, Grid Stability Systems
• Chemical Processing: Batch Process Safety, Hazardous Material Handling, Emergency Ventilation Control
• General Industry: Critical Machine Safety, Elevator Emergency Control, Nuclear Plant Auxiliary Systems
5. Compatibility & Model Comparison
Compatible Systems: Rockwell Automation Trusted Safety System, Trusted TMR Chassis, CS300 Expansion Chassis
Related Modules:
- T8151B: Trusted Ethernet Communication Interface (For Engineering Workstation Connection)
- T8311: Trusted Expander Interface (For CS300 Chassis Expansion)
- T8401: Trusted Digital Input Module (32 Channels, 24 V DC)
T8111 vs T8111C Comparison:
- T8111: Standard TMR Processor (No Conformal Coating, Lower Cost, Suitable for General Industrial Environments)
- T8111C: Conformal-Coated Version (Corrosion Resistant, Higher Reliability in Harsh/Corrosive Environments)
Technical Documentation | ICS TRIPLEX T8111C / T8111 | Trusted TMR Processor Module
