ICS Triplex T8312-4 Trusted TMR Expander Interface Adapter Unit--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ICS Triplex T8312-4 Trusted TMR Expander Interface Adapter Unit

Expander Interface Adapter for Connecting Controller & Expander Chassis in Trusted TMR Safety Instrumented Systems

1. Product Overview

The ICS Triplex T8312-4 is a Trusted TMR (Triple Modular Redundant) Expander Interface Adapter Unit, manufactured by ICS Triplex (now part of Honeywell Process Solutions). It enables seamless interconnection between the controller chassis and up to four expander chassis in Trusted safety instrumented systems (SIS) and distributed control systems (DCS). With full EMC shielding, locking connectors, and TMR architecture, it ensures reliable data communication and fault tolerance for critical industrial processes in oil & gas, chemical, power generation, and other high-risk industries, supporting system scalability and stable operation in harsh environments.

T8312-4 -3.jpg

2. Key Technical Specifications

• Product Type: Trusted TMR Expander Interface Adapter Unit (Chassis Interconnection)

• Brand & Model: ICS Triplex T8312-4 (Trusted TMR Series)

• Max Expander Chassis Support: Up to 4 Expander Chassis (Controller Chassis ID = 1, Expander IDs = 2-5)

• Architecture: Triple Modular Redundant (TMR) for Fault Tolerance & High Availability

• EMC Shielding: Fully Shielded (Compliant with IEC 61000-4 EMC Standards)

• Connectors: Locking Connectors (Prevent Accidental Disconnection)

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

• Storage Temperature: -40°C to +85°C (-40°F to +185°F)

• Humidity: 5% - 95% RH (Non-Condensing)

• Dimensions: 133 × 133 × 63 mm (5.3 × 5.3 × 2.5 in)

• Weight: 1.2 kg (2.6 lbs)

• Mounting: Rack Mount in Trusted Controller/Expander Chassis (Standard 19" Rack)

• Communication: Supports TMR Backplane Communication (Controller-Expander Data Exchange)

• Diagnostic: Comprehensive Self-Diagnostics for Module Status Monitoring

• Certification: CE, UL 508, ATEX/IECEx (Hazardous Area Compliance)

T8312-4 -1.jpg

3. Core Features

• TMR Architecture: Triple Modular Redundant Design for Fault Tolerance & No Single Point of Failure.

• Chassis Interconnection: Connects Controller Chassis to Up to 4 Expander Chassis for System Scalability.

• EMC Shielding: Fully Shielded Housing for Stable Performance in High-Noise Industrial Environments.

• Locking Connectors: Secure Connections to Prevent Vibration-Induced Disconnections.

• DIP Switch Configuration: Easy Setup of Controller (ID=1) & Expander Chassis IDs (2-5).

• Hot-Swappable: Supports Hot-Swap for Online Maintenance (No System Shutdown).

• Comprehensive Diagnostics: Real-Time Status Monitoring & Fault Reporting for Rapid Troubleshooting.

4. Typical Applications

• Safety Instrumented Systems (SIS): High-Risk Process Safety Shutdown & Emergency Trip Systems.

• Distributed Control Systems (DCS): Expanded I/O Chassis Interconnection for Process Control.

• Oil & Gas: Offshore Platforms, Refineries, and Pipeline Control System Expansion.

• Chemical Industry: Reactor Control and Hazardous Material Processing Safety Systems.

• Power Generation: Turbine, Generator, and Boiler Control System Chassis Expansion.

• Pulp & Paper: Paper Machine Safety Interlocks and Process Control System Scalability.

T8312-4 -2.jpg

5. Installation & Maintenance

• Mounting: 19" Rack Mount in Trusted Controller/Expander Chassis (Secure Fastening for Vibration Resistance).

• DIP Switch Setup: Set Controller ID = 1, Expander IDs = 2-5 (Refer to System Manual for Details).

• Wiring: Connect to Controller Backplane & Expander Chassis via Locking Cables (Shielded for EMC).

• Configuration: System Software Setup (Assign Chassis IDs, Enable TMR Communication).

• Maintenance: Hot-Swappable for Online Replacement; Regular Connector/Shield Inspection.

• Troubleshooting: Use Trusted Diagnostics Tools to Check Module Status, Communication Links, and Chassis IDs.

Technical Document | ICS Triplex T8312-4 | Trusted TMR Expander Interface Adapter | Honeywell Process Solutions
