ABB D674A906U01 U‑high HART / Std. FET 300 Electronic Cartridge--KIMI

Warehouse: Spot
Warranty： 365 days
Quality: Original module
Condition： New
Shipping method: Courier delivery

Contact person: LI MING
Contact number: +86 18059884790
WeChat：18059884790
E-mail: plc66@qq.com

Product Description

ABB D674A906U01 U‑high HART / Std. FET 300 Electronic Cartridge

Electronic Module for ABB ProcessMaster / FET 300 Electromagnetic Flowmeters, Signal Processing & HART Communication

1. Product Overview

The ABB D674A906U01 is a dedicated electronic cartridge (U‑high HART / Std. FET 300) designed for ABB ProcessMaster and FET 300 series electromagnetic flowmeters. It serves as the core signal processing and communication unit, converting high‑frequency flow sensor signals into standard 4‑20 mA analog output with HART digital communication capabilities. This module enables precise flow measurement, remote parameter configuration, and real‑time diagnostics, ensuring reliable data integration with DCS/PLC systems. With industrial‑grade design and compatibility with ABB’s flow measurement ecosystem, it is widely used in chemical, oil & gas, water & wastewater, and power generation industries for accurate flow monitoring and process control.

D674A906U01 FET3251COP1B4COH2.jpg

2. Key Technical Specifications

• Product Type: Electronic Cartridge for Electromagnetic Flowmeters (U‑high HART / Std. FET 300)

• Brand & Model: ABB D674A906U01 (Compatible with ProcessMaster / FET 300 Series)

• Core Function: Signal Conversion, Processing, HART Communication, Diagnostics

• Input: High‑frequency Flow Sensor Signals (from ABB Electromagnetic Flow Sensors)

• Output: 4‑20 mA DC Analog Signal + HART Digital Communication (Two‑Wire Loop)

• Power Supply: 24 VDC (Loop‑Powered via 4‑20 mA Signal)

• Operating Temperature: -20°C to +70°C (-4°F to +158°F)

• Humidity: 5%‑95% RH (Non‑Condensing)

• Protection Class: IP20 (Indoor Panel Mount)

• Weight: 0.25 kg (0.55 lbs)

• Communication Protocol: HART (Remote Configuration & Diagnostics)

• Application: ABB ProcessMaster / FET 300 Electromagnetic Flowmeter Systems

• Origin: Germany

D674A906U01 FET3251COP1B4COH2 -3.jpg

3. Core Features

• High‑Precision Signal Processing: Converts sensor signals to stable 4‑20 mA output with minimal drift.

• HART Communication: Supports remote parameter setting, range calibration, and diagnostic data access.

• Plug‑and‑Play Integration: Seamless compatibility with ABB ProcessMaster / FET 300 flowmeters.

• Built‑in Diagnostics: Monitors sensor health, signal integrity, and module status for proactive maintenance.

• Compact Design: Easy to install and replace in control cabinets, saving space.

• Industrial Reliability: Resistant to electrical interference, suitable for harsh industrial environments.

D674A906U01 FET3251COP1B4COH2 -2.jpg

4. Typical Applications

• Chemical Industry: Corrosive Liquid Flow Measurement & Process Control.

• Oil & Gas: Pipeline Flow Monitoring, Crude Oil & Refined Product Measurement.

• Water & Wastewater: Water Treatment Plant Flow Regulation, Sewage Flow Monitoring.

• Power Generation: Cooling Water, Boiler Feedwater Flow Measurement.

• Food & Beverage: Sanitary Flow Monitoring (with ABB Hygienic Flow Sensors).

D674A906U01 FET3251COP1B4COH2 -1.jpg

5. Installation & Maintenance

• Mounting: Panel‑mount in control cabinet; Ensure proper alignment with flowmeter sensor connections.

• Wiring: Connect 4‑20 mA loop cables to terminal block; Use shielded cables to avoid signal interference.

• Configuration: Use ABB FlowMaster or HART Communicator to set range, units, and alarm thresholds.

• Calibration: Factory‑calibrated; Field calibration via HART protocol (no manual adjustment needed).

• Maintenance: Periodically check connection integrity and power supply; Use diagnostic data for fault detection.

Technical Document | ABB D674A906U01 | U‑high HART / Std. FET 300 Electronic Cartridge | ProcessMaster / FET 300 Flowmeters
