GE IS200TTURH1CFD Turbine Specific Primary Trip Terminal Board for Speedtronic Mark VI/VIe Systems

Product Description

The GE IS200TTURH1CFD is a turbine-specific primary trip terminal board engineered for GE Speedtronic Mark VI and Mark VIe turbine control systems, serving as a critical interface for turbine protection signals in gas and steam turbine applications. It facilitates seamless connection between field safety devices (e.g., overspeed sensors, temperature switches, pressure transmitters) and the main control system, supporting both simplex and TMR (Triple Modular Redundancy) configurations via hardware jumpers. The board features isolated signal channels, robust circuit protection, and compatibility with VTUR/PTUR modules for generator synchronization and turbine trip logic execution. Designed for industrial durability, it operates reliably in -20°C to +60°C temperature ranges, with compliance to IEC 61010 safety standards and IP20 front-panel protection, ensuring long-term stability in power generation, oil & gas, and industrial turbine control environments.

Key Functions

The IS200TTURH1CFD delivers core turbine protection terminal capabilities: Primary trip signal interface for field safety devices (overspeed, temperature, pressure, vibration) to trigger emergency shutdown (ESD) when safety thresholds are exceeded; Support for TMR/simplex system configurations via hardware jumpers, enabling flexible redundancy deployment; Isolated signal channels to prevent cross-talk, ground loops, and EMI/RFI interference, ensuring signal integrity; Compatibility with VTUR/PTUR modules for generator synchronization and turbine control logic integration; Real-time signal routing to main control processors for fast trip response (≤10ms typical); Hardware fault diagnostics for open/short circuit detection and module health monitoring; Hot-swappable design for maintenance without system shutdown; Redundant power input compatibility to prevent protection system failure during power anomalies.

Application Scenarios

The IS200TTURH1CFD is ideal for turbine protection terminal tasks in mission-critical industrial applications: Power generation (thermal, nuclear, combined-cycle plants) for gas/steam turbine overspeed protection, bearing temperature monitoring, and lubrication system fault detection; Oil & gas upstream/midstream for compressor turbine trip control, pipeline pressure safety interlocks, and wellhead turbine protection; Industrial turbine systems (chemical, pulp & paper, mining) for process-driven turbine safety, ensuring operational compliance and asset protection; TMR system retrofits and upgrades, replacing legacy terminal boards with TMR-capable hardware for enhanced reliability; Turbine control system expansion, adding redundant protection channels to meet safety integrity level (SIL) requirements; Emergency shutdown (ESD) system integration, providing a dedicated terminal interface for safety-critical signals to minimize trip response time and prevent catastrophic equipment damage.

Technical Specifications
