Bently Nevada 3500/72M 176449-08 4-Channel Reciprocating Rod Position Monitor--KIMI
- Part number：3500/72M 176449-08
- Product Origin：America
- HS CODE：8479909090
- Warehouse: Spot
- Warranty： 365 days
- Quality: Original module
- Condition： New
- Shipping method: Courier delivery
- Contact person: LI MING
- Contact number: +86 18059884790
- WeChat：18059884790
- E-mail: plc66@qq.com
Product Description
Bently Nevada 3500/72M 176449-08 4-Channel Reciprocating Rod Position Monitor
4-Channel Reciprocating Rod Position Monitoring for Reciprocating Compressors, Rod Position/Rod Drop/Hyper-Compressor Monitoring
1. Product Overview
The Bently Nevada 3500/72M 176449-08 is a 4-channel reciprocating rod position monitor for 3500 machinery protection systems, designed to monitor reciprocating compressor rod position, rod drop, and hyper-compressor motion via Bently Nevada eddy current proximity probe signals. It processes dynamic/static position measurements, compares them to user-programmable alarm thresholds, and triggers alerts to prevent catastrophic failures. Channels are programmed in pairs (Channels 1-2 & 3-4), supporting up to two monitoring functions simultaneously. With hot-swappable design, redundant power compatibility, and hazardous area certification, it is ideal for oil & gas, petrochemical, and heavy manufacturing industries, ensuring reliable protection for reciprocating compressors.
2. Key Technical Specifications
• Brand & Model: Bently Nevada 3500/72M (PN: 176449-08, 4-Channel Reciprocating Rod Position Monitor)
• Product Type: 4-Channel Reciprocating Rod Position/Rod Drop/Hyper-Compressor Monitor
• Input: 4 Channels of Bently Nevada Eddy Current Proximity Probe Signals
• Input Impedance: 10 kΩ (Probe Input)
• Monitoring Functions: Rod Position, Rod Drop, Hyper-Compressor Motion (Pair Programming)
• Alarm Configuration: Programmable Warning/Danger Alarms (User-Defined Thresholds)
• Outputs: Configurable Relay Contacts + 4-20 mA (Optional)+Digital Communication (Modbus)
• Power Consumption: 8 Watts (3500 Rack Backplane Power)
• Form Factor: Full-Height 3500 System Module
• Redundancy: Redundant Power Supply Compatible
• Hot Swap: Supported (No System Interruption with Redundant Supply)
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Dimensions: 241.3 mm × 24.4 mm × 241.8 mm (9.50 in × 0.96 in × 9.52 in)
• Weight: Approx. 0.91 kg (2.0 lbs)
• Certifications: CSA/NRTL/C (Class 1, Div 2), ATEX/IECEx (Zone 2)
3. Core Features
• 4-Channel Monitoring: Comprehensive Coverage for Reciprocating Compressor Rods/Pistons
• Pair Programming: Channels 1-2 & 3-4 Enable Up to Two Monitoring Functions Simultaneously
• Multi-Function Monitoring: Rod Position, Rod Drop, Hyper-Compressor Motion Detection
• Programmable Alarms: Warning/Danger Thresholds for Early Fault Detection
• Hot-Swappable: Online Module Replacement without System Shutdown
• Versatile Outputs: Relays + 4-20 mA + Digital Communication for Integration
• Hazardous Area Certified: Class 1, Div 2 / Zone 2 for Explosive Environments
• Industrial-Grade Design: Operates in -40°C to +70°C (-40°F to +158°F) Temperatures
4. Typical Applications
• Oil & Gas: Reciprocating Compressor Rod Position Monitoring for Early Wear Detection.
• Petrochemical Refineries: Hyper-Compressor Motion Monitoring for Process Safety.
• Power Generation: Reciprocating Pump Rod Drop Monitoring for Unplanned Downtime Prevention.
• Heavy Manufacturing: Reciprocating Compressor Rod Position Protection for Equipment Safety.
• Marine Propulsion: Reciprocating Engine Rod Position Monitoring for Performance Optimization.
• Mining: Reciprocating Compressor Rod Drop Detection for Maintenance Planning.
5. Installation & Maintenance
Installation Steps
• Mounting: 3500 Rack Slot (Non-Power Slot, Ensure Backplane Connection).
• Wiring: Connect 4 Eddy Current Probe Inputs + Relay/Digital Outputs.
• Configuration: Set Monitoring Functions (Pair Programming)+Alarm Thresholds via 3500 Software.
• Testing: Verify Probe Signal Reception & Alarm Trigger Accuracy.
Maintenance Tips
• Daily: Monitor Module Health & Alarm Status via 3500 HMI/DCS.
• Weekly: Inspect Probe Cables/Connectors for Damage/Loose Connections.
• Monthly: Validate Position Measurement Accuracy & Alarm Consistency.
• Quarterly: Perform Backplane Communication & Relay Function Checks.
• Annual: Calibrate Probe Inputs & Update Firmware (Per Vendor Guidelines).
Technical Document | Bently Nevada 3500/72M 176449-08 | 4-Channel Reciprocating Rod Position Monitor | Machinery Protection Systems
