ABB 500CSP04 (HE4013140002/1MRB150051R2) Communication & Power Supply Module
Integrated Power Supply & FBP Bus Expansion for ABB AC500 PLC Automation Systems
1. Core Product Overview
The ABB 500CSP04 (order codes: HE4013140002 / 1MRB150051R2) is an integrated communication and power supply module exclusively designed for the ABB AC500 PLC series, serving as a critical hub for system power distribution, FBP (Flexible Bus Protocol) bus expansion and auxiliary communication conversion in distributed automation systems. It integrates a high-stability industrial power supply unit and ABB’s proprietary FBP bus controller, providing reliable 24V DC power for AC500 I/O modules while enabling long-distance FBP bus expansion for distributed I/O deployment in large-scale industrial sites. With industrial-grade rugged design, it supports -20°C to +70°C operating temperature, IP20 front protection, and EMC/surge resistance, ensuring stable power supply and bus communication in harsh industrial environments such as chemical plants, power stations, metallurgy and water treatment systems. Fully compatible with all AC500 series CPUs (500CPU03/02/01) and I/O modules, it is a key component for building scalable AC500 PLC systems.
• Core Role: AC500 system power distribution; FBP bus expansion/relay; I/O module 24V DC power supply; auxiliary communication conversion; distributed I/O hub
• Model Info: 500CSP04 (base model); HE4013140002/1MRB150051R2 (ABB official order codes); AC500 communication & power module
• Key Specs: Integrated 24V DC power supply; FBP bus master/slave support; max 32 I/O module expansion; -20°C~+70°C operating temp; redundant power input optional
• Reliability: EMC/surge protection (IEC 61000-4); overvoltage/overcurrent protection; anti-vibration (IEC 60068); IP20 front dust protection
2. Industrial Power Supply Specifications
The 500CSP04 is equipped with a high-efficiency, low-ripple industrial switch power supply unit, designed for stable power distribution to AC500 I/O modules and field sensors. It supports 100-240V AC wide-range input (50/60Hz) with active PFC for high power factor, and outputs regulated 24V DC with rated current of 4A (max 5A peak), capable of powering up to 32 AC500 series I/O modules in a single FBP bus chain. The power supply unit integrates multi-level protection functions: overvoltage protection (28V DC cutoff), overcurrent protection (auto-recovery), short-circuit protection and thermal overload protection, effectively preventing damage to the module and connected I/O devices caused by power anomalies. It also supports optional 24V DC redundant power input, further improving the power supply reliability of critical industrial automation systems.
• Input: 100-240V AC (50/60Hz) wide range; active PFC; optional 24V DC redundant input
• Output: 24V DC regulated; 4A rated current; 5A peak current; low ripple (<50mV); 85% high efficiency
• Power Protection: 28V DC overvoltage cutoff; overcurrent auto-recovery; short-circuit protection; thermal overload protection
• Power Capacity: Drives up to 32 AC500 I/O modules; 24V DC sensor excitation output; isolated power for FBP bus
3. FBP Bus Expansion & Communication
The 500CSP04 is built with a high-speed ABB FBP bus controller, supporting both master and slave working modes for flexible AC500 system expansion. As a FBP bus relay/hub, it extends the maximum transmission distance of the FBP bus to 1000m (at 1Mbps baud rate) with RS485 physical layer, enabling distributed deployment of AC500 I/O modules in large industrial plants without signal attenuation. It supports auto-baud rate detection (125Kbps~1Mbps) and bus fault self-diagnosis, with front-panel LED indicators for real-time monitoring of FBP bus status (link/activity/fault). The module also provides an auxiliary RS485 communication port (Modbus RTU) for connection with third-party field devices, realizing data exchange between AC500 PLC and non-ABB industrial equipment. The FBP bus adopts channel-to-ground isolation (2.5kV) and EMC filtering, effectively resisting industrial electromagnetic interference and ensuring stable bus communication.
• FBP Bus: RS485 physical layer; 125Kbps~1Mbps auto-baud; max 1000m transmission distance; 2.5kV isolation
• Expansion Capacity: Max 32 AC500 I/O modules per bus chain; master/slave mode configurable; multi-bus chain support
• Auxiliary Communication: 1×RS485 port (Modbus RTU); multi-master/slave; 9600-115200bps baud rate
• Bus Diagnostics: Front-panel LED status indicators; bus fault self-diagnosis; fault alarm output; real-time bus activity monitoring
4. AC500 Integration & Installation
The 500CSP04 achieves plug-and-play integration with all ABB AC500 series CPUs (500CPU03/02/01) and I/O modules, requiring no additional configuration for basic power supply and FBP bus communication. It features standard 35mm DIN rail mounting with a compact form factor (120×100×65mm), fitting into standard industrial control cabinets and distributed I/O enclosures, and supports cascade installation for multi-bus chain expansion in large-scale systems. The front panel is designed with clear LED indicators (Power/AC Input/DC Output/FBP Link/FBP Activity/Fault) for one-click visual diagnosis of module and bus status, and the terminal blocks adopt spring-type wiring for fast and reliable connection, reducing on-site installation time. The module is fully compliant with IEC 61131-2 industrial control equipment standards, and its rugged mechanical design resists industrial vibration (5-50Hz) and shock, adapting to harsh on-site installation conditions.
• Compatibility: Plug-and-play with AC500 CPUs (500CPU03/02/01) and all AC500 I/O modules; no additional configuration required
• Mounting: 35mm standard DIN rail; 120×100×65mm compact dimensions; cascade installation for multi-bus expansion
• Wiring: Spring-type terminal blocks; fast on-site wiring; detachable terminal for easy maintenance
• Diagnostics: Front-panel multi-LED indicators; real-time status monitoring; fault alarm output; easy on-site troubleshooting
5. Typical Applications & Industrial Compliance
Key Industrial Sectors: Chemical/petrochemical process control; thermal/hydro/wind power generation; steel/metallurgy automation; water/wastewater treatment; building automation; mining machinery; automotive/packaging manufacturing; large-scale production line automation.
Core Use Cases: AC500 PLC system power distribution; FBP bus long-distance expansion; distributed I/O module hub; critical system redundant power supply; AC500 PLC with third-party device data exchange; large-scale industrial automation system I/O expansion.
Certifications & Compliance: IEC 61131-2 (industrial control equipment); IEC 61010-1 (electrical safety); IEC 61000-4 (EMC/surge); IEC 60068 (environmental testing); CE/UL/RoHS certified; -20°C to +70°C operating temperature; IP20 front protection.
Spare Part & Warranty: ABB genuine original module; factory pre-tested for power/communication performance; 18-month standard warranty; fully compatible with all AC500 system firmware versions; technical support for system bus configuration and expansion.
